Summary
CHAPTER 6
Detailed Parameter Description
6.1 Access and Read Only Parameters - P000 to P099.........................87
6.2 Regulation Parameters - P100 to P199 ............................................ 97
6.3CongurationParameters-P200toP299........................................106
6.4 Serial Communication Parameters - P300 to P399 .......................... 119
6.5 Motor Parameters - P400 to P499 .................................................... 121
6.6 Special Function Parameters - P500 to P599 ..................................122
6.7 Protection Parameters - P600 to P699 ............................................. 128
6.8 Selection Between Fault and Alarm - P700 to P790 ........................140
6.9SoftPLCParameters-P950toP999................................................142
CHAPTER 7
Programming Information and Suggestions
7.1 Applications and Programming ......................................................... 143
7.1.1 Starting by Voltage Ramp (P202=0) ........................................... 145
7.1.2StartingbyCurrentLimit(P202=1) ............................................. 146
7.1.3 Starting by Current Ramp with High Initial Current (P202=4) .....147
7.1.4StartingbyCurrentRampwithLowInitialCurrent(P202=4) .....148
7.1.5 Starting with Pump Control (P202=2) ......................................... 149
7.1.6 Starting with Torque Control (P202=3) .......................................151
7.1.6.1LoadswithConstantTorque(P202=3andP120=1point) ..152
7.1.6.2LoadswithHigherInitialTorque
(P202=3 and P120=3 points) .............................................152
7.1.6.3LoadswithConstantTorqueandSSpeedCurve
(P202=3 and 120=3 points) ................................................ 153
7.1.6.4LoadswithQuadraticTorqueandSSpeedCurve
(P202=3 and P120=2 points) ..............................................153
7.1.6.5LoadswithQuadraticTorqueandLinearSpeedCurve
(P202=3 and P120=3 points) .............................................154
7.1.6.6LoadswithQuadraticTorqueandHigherInitialTorque
(P202=3 and P120=3 points) ..............................................154
7.1.6.7HydraulicPumpLoadType(P202=3) ................................155
7.2 Protections and Programming ..........................................................158
7.2.1 Thermal Classes.........................................................................158
7.2.1.1 Suggestions on How to Set Thermal Class ........................158
7.2.1.2 Example on How to Set the Thermal Class ........................ 159
7.2.1.3 Time Reduction When Changing from Cold Starting to
Hot Starting ........................................................................160
7.2.1.4 Service Factor ....................................................................160
7.2.2 Under- and Over- Protections ....................................................161
7.2.2.1 Undervoltage and Overvoltage protection .......................... 161
7.2.2.2 Underload Protection ..........................................................161
7.2.2.3 Overload Protection ............................................................161

Table of Contents
