WEG SSW-06 User Manual

CHAPTER 6 - DETAILED PARAMETER DESCRIPTION
94
 Indication of the state of motor thermal protection on a scale of 0%
to 250%. 250 being the thermal protection functioning point of the
motor, indicating an error.
 The value indicated in this parameter depends on the motor working
condition and how long it has been in this condition, for example:
stopped, starting or in full operation. The value also depends on the
selected thermal class, the nominal power and the service factor of
the motor.
 A value of approximately 160 can be read if the motor is operating in
full load for over 2 hours with a current equal to the nominal current
times the service factor (In x S.F. @ 2h).
 If P204 is set to 3, P050 is reset to zero.
 This value remains stored even when the Soft-Starter is turned OFF.
P050 0 to 250
Motor Thermal [ - ]
Protection Status 1%
Range
[Factory Setting]
Parameter Unit Description / Notes
canreachitsnominalspeedwithlowvoltages.Andthetimeadjusted
in P102 is the time in which the Soft-Starter applies 100% of the line
voltage to the motor.
 The value of P049 is reset at the beginning of each start.
 If P204 is set to 3, P049 is reset to zero.
 This value is not kept when the Soft-Starter is turned OFF.
P053
Maximum Current at
Full Voltage
 It stores the value of the maximum current during the period the
motor is working at full voltage or with the By-pass activated.
 If P204 is set to 4, P053 is reset to zero.
 This value remains stored even when the Soft-Starter is turned
OFF.
0 to 9999.9
[ - ]
0.1A
P054
MaximumLineVol-
tage with the Motor
Running
 It stores the highest line voltage value with the motor in operation.
 If P204 is set to 4, P054 is reset to zero.
 This value remains stored even when the Soft-Starter is turned
OFF.
0 to 999
[ - ]
1V
P055
MinimumLineVoltage
with the Motor Run-
ning
 It stores the lowest line voltage value with the motor in operation.
 If P204 is set to 4, P055 is reset to zero.
 This value remains stored even when the Soft-Starter is turned OFF.
0 to 999
[ - ]
1V
P056
MaximumLineFre-
quency with the Motor
Running
 It stores the highest line frequency value with the motor in operation.
 If P204 is set to 4, P056 is reset to zero.
 This value remains stored even when the Soft-Starter is turned OFF.
0 to 99
[ - ]
1Hz
