P057
MinimumLineFre-
quency with the Motor
Running
 It stores the lowest line frequency value with the motor in operation.
 If P204 is set to 4, P057 is reset to zero.
 This value remains stored even when the Soft-Starter is turned OFF.
0 to 99
[ - ]
1Hz
P058
Maximum Number of
Starts per Hour
 It stores the maximum number of starts per hour.
 It has the capacity of storing one start every 112.5 s, totalizing a
maximum of 32 starts in one hour. If two or more starts occur during
this time period of 112.5 s, only one is recorded.
 If P204 is set to 4, P058 is reset to zero.
 This value remains stored even when the Soft-Starter is turned OFF.
0 to 32
[ - ]
1
P059
Total Number of Starts
 It stores the total number of starts executed by the Soft-Starter.
 In order to be considered a start, the motor must initiate the starting
after the initial test, i.e., the line and motor connections must be
correct.
 This value remains stored even when the Soft-Starter is turned OFF.
0 to 65535
[ - ]
1
P060, P063, P066,
P069, P072 and P075
Current at the Fault
Trip
P061, P064, P067,
P070, P073 and P076
Voltage at the Fault
Trip
P062, P065, P068,
P071, P074 and P077
SSW Status at the
Fault Trip
 P060, P063, P066, P069, P072 and P075 stores the motor current
value at the moment of the fault trip, according to the table 6.2.
 P061, P064, P067, P070, P073 and P076 stores the motor voltage
value at the moment of the fault trip, according to the table 6.2.
 P062, P065, P068, P071, P074 and P077 stores the Soft-Starter
status at the moment of the fault trip, according to the table 6.2.
The Soft-Starter status are described in the parameter P006.
 This value remains stored even when the Soft-Starter is turned
OFF.
0 to 9999.9
[ - ]
0.1A
0 to 999
[ - ]
0.1A
0 to 12
[ - ]
1
Table 6.2 - Sequence of faults and their respective diagnostics
Sequence
of Faults
Related
Parameters
Parameter Descriptions
P014
(Last)
P060 Motor current at the last fault trip
P061 Linevoltageatthelastfaulttrip
P062 Soft-Starter status at the last fault trip
P015
(2nd)
P063 Motor current at the second fault trip
P064 Linevoltageatthesecondfaulttrip
P065 Soft-Starter status at the second fault trip
P016
(3rd)
P066 Motor current at the third fault trip
P067 Linevoltageatthethirdfaulttrip
P068 Soft-Starter status at the third fault trip
P017
(4th)
P069 Motor current at the fourth fault trip
P070 Linevoltageatthefourthfaulttrip
P071 Soft-Starter status at the fourth fault trip
P018
(5th)
P072 Motorcurrentatthefthfaulttrip
P073 Linevoltageatthefthfaulttrip
P074 Soft-Starterstatusatthefthfaulttrip
P019
(6th)
P075 Motor current at the sixth fault trip
P076 Linevoltageatthesixthfaulttrip
P077 Soft-Starter status at the sixth fault trip
