CHAPTER 6 - DETAILED PARAMETER DESCRIPTION
96
Range
[Factory Setting]
Parameter Unit Description / Notes
P085 0 to 3
Fieldbus [ - ]
Communication -
Board Status
 Indicates the status of the Fieldbus communication board.
 Standard is disabled when board is not inserted.
 For more details, refer to the Fieldbus Manual for the Soft-Starter
SSW-06.
Table 6.3 - Fieldbus communication board status
P088 0 to 4
SoftPLCStatus [-]
1
ItindicatestheexistenceofanyuserPLCsoftwarestored.Ifthere
is any, it indicates its actual state.
Table 6.4 - Status of the applicative software
P089 0 to 1
AllowsSoftPLC [-]
1
 The SSW-06 Soft-Starter allows the implementation of programmab-
lelogiccontrollersoftwareinladderlanguage,theSoftPLC,with
an applicative program capacity of 1 Kbyte.
Withthe SoftPLC,interlockinglogics betweendigitalinputs and
outputs, analog outputs, motor starting logics, among others, can
be created.
ThisSoftPLCisprogrammablethroughtheWLPsoftware,according
totheWLPmanual.
Table 6.5 - Indication of the SoftPLC use capacity
 It indicates if the Soft-Starter control board has the memory capacity
forusingtheSoftPLC.TheolderSoft-Startercontrolboardsdonot
have this capacity.
 The Soft-Starter software versions are compatible with both boards,
onlytheSoftPLCcannotbeusedwiththeolderboards.
P091 0 to 250
Motor Temperature Ch1 [ - ]
ºC
P092
Motor Temperature Ch2
P093
Motor Temperature Ch3
P094
Motor Temperature Ch4
P095
Motor Temperature Ch5
Indicates the motor temperature in Celsius degrees.
NOTE!
For the indication of the temperatures of the motor the use
of optional kit K-PT100 is necessary. For more details see
chapter 9.
P085
Description
0
O󰀨
1
Board inactive
2
BoardactiveandO󰀪ine
3
Board active and Online
P088 Description
0 Without applicative software
1 Loadingtheapplicativesoftware
2 Fault in the applicative software
3 Stopped applicative software
4 Running the applicative software
P089 Description
0 It does not allow applicative software
1 It allows applicative software
