14 Technical specifications
Battery Approved CR 2032-1HFE
3 V lithium cell
Operating temperature
Min. +5 °C
Max. +55 °C
Storage temperature
Min. -25 °C
Max. +70 °C
IP protection rating IP 50
Dimensions
Basic length
Outside (A) 30.7 mm
Inside (B) 32.4 mm
Extensions On both sides, increments of
5 mm
Total length, maximum 180 mm
Cam positions in key with-
drawal position
EUR 8
Battery Contained in the battery
replacement set:
Ä
“Spare part set”
on page 177
Temperature at installation
location
Min. +5 °C
Max. +55 °C
IP protection rating IP 54
VdS environmental class EUR 2
Active key/Masterkey
Cylinder type 01 and type 05
Technical specifications
23.03.2020 blueCompact electronic locking system 181
