5.2.1 Install reader with internal control unit
Personnel:
n
Qualified electrician for energy
and building technology
Protective equip-
ment:
n
Safety shoes
n
Hearing protection
Special tool:
n
Impact drill incl. drill set
n
Drilling template
n
Voltmeter
Materials:
n
Dowel
n
Taut wire
n
Screws
Prerequisites:
n Empty conduit for cable routing has been laid.
n Reader and reader cable are ready.
1. Drill the holes in the wall in accordance with the drill
template.
2. Insert dowels in both holes.
3. Feed the taut wire into the empty conduit.
4. Carefully remove the reader housing. To do this, press
lightly against the reader housing from below until the
reader housing folds open to the front.
5. Connect the connector of the reader with the mating
connector of the connection cable.
6. Feed the cable carefully into the empty conduit using
the taut wire.
7.
NOTICE!
Damage to the reader and periphery
due to excessive tightening torque!
Screw on the reader by hand.
8. Place the reader housing on the exposed reader and
engage.
ð
The reader has been installed.
9.
NOTICE!
Functional fault due to incomplete
wiring!
Only activate the power supply once the wiring has
been completed in full.
Prepare electrical installation
Power supply wiring
Select and install reader
23.03.2020blueCompact electronic locking system66
