148 RT System 2 v2.3 Deployment Guide R01.i
© 2010-2014 Wireless Seismic, Inc. All rights reserved.
B. WRU and LIU Specifications
LIU Specifications
B.2 LIU Specifications
The following table provides the LIU Specifications:
Weight with 2 batteries and antenna 1C WRU:
Standard – 6.5 lbs. (2.95 Kg)
High capacity – 7.71 lbs. (3.50 kg)
3C WRU:
High capacity – 8.33 lbs. (3.78 kg)
Table B–1 WRU Specifications (cont.)
Item Description
Table B–2 LIU Specifications
Item Description
Maximum PoE output power 40W
Power source 12V DC (+20% tolerance) battery
Operating temperature -40°C to +75°C
Humidity 0 to 100%
Environmental Rating IP67
Dimensions 5.42 W x 9.44 H x 14.21 L inches
(24 W x 14 H x 36 L centimeters)
Weight 13 lbs. (5.9 Kg)
Current Rating 5 A
Operating Frequency Range 2403 MHz to 2475 MHz
