C. Radio Specifications
Antenna Specifications
The supported line station antenna specifications are as follows:
Figure C–2 6 dBi Antenna (65-0179)
Table C–1 Antenna Specifications, 6 dBi (65-0179)
Item Description Radiation Patterns
Model T58060O10006
Frequency Range 5725 to 5850 MHz
Bandwidth 125 MHz
Gain 6 dBi
Vertical Beamwidth 25°
VSWR -/= 1.5
Impedance 50 Ohms
Polarization Vertical
