3. Backhaul
Backhaul Components
BK-8 1
– Hammer, 2.5 lb (70-0064)
YY—
BK-9 1
– Pry Bar, 15 in (70-0065)
YY—
BK-10 2
– Flagging Roll, Orange (70-
0066)
YY—
BK-11 1
– Compass Sighting (70-
0067)
YY“F. Using a Compass” on
page 184
BK-12 5
– Hose Clamp, 2 in (70-
0142)
YY—
BK-13 2
– Hose Clamp, 0.5 in (70-
0084)
YY—
BK-14 15
ft
– Wire, 18AWG Green (65-
0077)
YY—
F-1 1 • Fiber Backhaul Kit, 250 m (15-
0037)
– OR –
• Fiber Backhaul Kit, 500 m (15-
0038)
Y Y —
F-2 1
– Media Converter (60-0017)
YY“Cable Assemblies” on page
45
F-3 1
– Cable, Backhaul Jumper
(60-0033)
YY“Cable Assemblies” on page
45
F-4 1
–Cable, Fiber Optic,
Armored, 250 m (60-0026)
– OR –
–Cable, Fiber Optic,
Armored, 500 m (60-0023)
YY“Cable Assemblies” on page
45
Table 3–2 Backhaul Components, LIU, Mast, and Fiber (cont.)
# EA Item Line Recorder Reference
Table 3–3 Backhaul Components, Radios
# EA Item Line Recorder Reference
LB-1
1
1
Ubiquiti Bullet Radio
Line Radio Kit (US) (15-0044)
– OR –
Line Radio Kit (Intl) (15-0053)
Y — —
LB-2 2 • 5 GHz Radio (US) (56-0019 US)
– OR –
• 5 GHz Radio (Intl) (56-0024)
Y—“Bullet Line Station Radios”
on page 157
LB-3 1 • 5.8 GHz 6 dBi Omni Antenna (65-
0179)
Y—“Bullet Line Station Antenna”
on page 149
