160 RT System 2 v2.3 Deployment Guide R01.i
© 2010-2014 Wireless Seismic, Inc. All rights reserved.
C. Radio Specifications
Radio Specifications
The power specifications for the Ubiquiti Rocket radio are as follows:
C.2.3 NanoStation Recorder/Line Station Radios
The specifications for the Ubiquiti NanoStation™ radio are as follows:
Table C–9 Rocket Recorder Radio Power Specifications (15-0052 US, 15-0054 Intl)
TX Power Specifications RX Power Specifications
11a
Data Rate Avg. TX T olerance
11a
Data Rate Ave. TX T olerance
6-24 Mbps 27 dBm +/-2 dB 6-24 Mbps -94 dBm min +/-2 dB
36 Mbps 25 dBm +/-2 dB 36 Mbps -80 dBm +/-2 dB
48 Mbps 23 dBm +/-2 dB 48 Mbps -77 dBm +/-2 dB
54 Mbps 22 dBm +/-2 dB 54 Mbps -75 dBm +/-2 dB
11n /
airMAX
MCS0 27 dBm +/- 2 dB
11n /
airMAX
MCS0 -96 dBm +/- 2 dB
MCS1 27 dBm +/- 2 dB MCS1 -95 dBm +/- 2 dB
MCS2 27 dBm +/- 2 dB MCS2 -92 dBm +/- 2 dB
MCS3 27 dBm +/- 2 dB MCS3 -90 dBm +/- 2 dB
MCS4 26 dBm +/- 2 dB MCS4 -86 dBm +/- 2 dB
MCS5 24 dBm +/- 2 dB MCS5 -83 dBm +/- 2 dB
MCS6 22 dBm +/- 2 dB MCS6 -77 dBm +/- 2 dB
MCS7 21 dBm +/- 2 dB MCS7 -74 dBm +/- 2 dB
MCS8 27 dBm +/- 2 dB MCS8 -95 dBm +/- 2 dB
MCS9 27 dBm +/- 2 dB MCS9 -93 dBm +/- 2 dB
MCS10 27 dBm +/- 2 dB MCS10 -90 dBm +/- 2 dB
MCS11 27 dBm +/- 2 dB MCS11 -87 dBm +/- 2 dB
MCS12 26 dBm +/- 2 dB MCS12 -84 dBm +/- 2 dB
MCS13 24 dBm +/- 2 dB MCS13 -79 dBm +/- 2 dB
MCS14 22 dBm +/- 2 dB MCS14 -78 dBm +/- 2 dB
MCS15 21 dBm +/- 2 dB MCS15 -75 dBm +/- 2 dB
Table C–10 NanoStation Radio Specifications (56-0035 US, 56-0032 Intl)
Item Description
System Information
Processor Specs Atheros MIPS 24KC, 400MHz
Memory Information 32MB SDRAM, 8MB Flash
Networking Interface 1 X 10/100 BASE-TX (Cat. 5, RJ-45) Ethernet
Regulatory / Compliance Information
