162 RT System 2 v2.3 Deployment Guide R01.i

© 2010-2014 Wireless Seismic, Inc. All rights reserved.

C. Radio Specifications

Radio Specifications

11n /

airMAX

MCS0 23 dBm +/-

2 dB

11n /

airMAX

MCS0 -96 dBm +/-

2 dB

MCS1 23 dBm +/-

2 dB

MCS1 -95 dBm +/-

2 dB

MCS2 23 dBm +/-

2 dB

MCS2 -92 dBm +/-

2 dB

MCS3 23 dBm +/-

2 dB

MCS3 -90 dBm +/-

2 dB

MCS4 22 dBm +/-

2 dB

MCS4 -86 dBm +/-

2 dB

MCS5 20 dBm +/-

2 dB

MCS5 -83 dBm +/-

2 dB

MCS6 18 dBm +/-

2 dB

MCS6 -77 dBm +/-

2 dB

MCS7 17 dBm +/-

2 dB

MCS7 -74 dBm +/-

2 dB

MCS8 23 dBm +/-

2 dB

MCS8 -95 dBm +/-

2 dB

MCS9 23 dBm +/-

2 dB

MCS9 -93 dBm +/-

2 dB

MCS10 23 dBm +/-

2 dB

MCS10 -90 dBm +/-

2 dB

MCS11 23 dBm +/-

2 dB

MCS11 -87 dBm +/-

2 dB

MCS12 22 dBm +/-

2 dB

MCS12 -84 dBm +/-

2 dB

MCS13 20 dBm +/-

2 dB

MCS13 -79 dBm +/-

2 dB

MCS14 18 dBm +/-

2 dB

MCS14 -78 dBm +/-

2 dB

MCS15 17 dBm +/-

2 dB

MCS15 -75 dBm +/-

2 dB

Table C–11 NanoStation Radio Power Specifications (56-0035 US, 56-0032 Intl) (cont.)

TX Power

Specifications

RX Power

Specifications
