Sawmill Operation
Preparing The Sawmill For Towing
4
4-19 60HDdoc102619 Sawmill Operation
See Figure 4-4.
CAUTION! It is important that the lower stop bolts are properly
adjusted to secure the carriage on the track rail. Failure to properly
adjust the stop bolts can cause saw head damage, especially during
mill transportation.
6. If necessary, adjust the stop located at the bottom of the mast so the saw head contacts them after it
is lowered 3/4" (19mm) past where it contacts the rest pin.
FIG. 4-4
