Sawmill Operation
Preparing The Sawmill For Towing
Sawmill Operation 60HDdoc102619 4-20
4
See Figure 4-5.
7. Use the hydraulic controls to raise the log turner and loader as high as they will go. Manually lift the
loader and hook the loader chains to the sawmill frame. Use the hydraulic loader lever to lower the
loader until the chains are tight. Push the loader lever down to bring the loader feet up to the loader
arms.
8. Hook the carriage safety chain located at the bottom of the carriage to the bracket at the bottom of
the mast.
See Figure 4-6.
CAUTION! Check to be sure the saw head safety chain is secured
before towing the sawmill. Failure to properly secure the saw head can
result in severe machine damage. Be sure the blade housing and
pulley covers are in place and secure. Use the safety retainer pin and
FIG. 4-5
FIG. 4-6
Loosen jam nut
and turn bolt
to raise or lower
stop bolt
Loosen jam nut
and turn bolt to
raise or lower
stop bolt
To Next Page
