Xerox® B205/B215 Multifunction Printer Service Manual
Product Specifications
Initial Release
General Procedures / Information
NOTE:
Declared yield value in accordance with ISO/IEC 19752.
Depending on the options and job mode used, the toner cartridge’s life span may differ.
When replacing a Toner/Print Cartridge, check model number and consumables code. Refer to
t
he Xerox® B215/B205 User Guide for information regarding ordering consumables.
Table 7 Paper Handling
Item Specification B205 / B215
Standard Capacity Paper Tray (Cassette) 250 sheets 80gsm
Multi Purpose Tray 1 sheet
Maximum Capacity 250 sheets 80gsm
Printing Minimum media size 8.5 x 14 in. (216 x 356 mm)
Maximum media size 3.0 x 5.0 in. (76 x 127 mm)
Main Paper Tray Capacity 250 sheets 80gsm
Media sizes 8.5 x 14 in. (legal) 8.5 x 11 in. (A4), 5.5 x 8.5
i
n. (A5), ISO B5, JIS B5, Executive, Oficio,
Folio
Media type Plain, Lightweight, Recycled, Heavy-weight,
Ar
chive
Media weight 16 to 58 lb (60 to 216 gsm)
Sensing No
Manual Feed Slot Capacity Plain paper and envelope 1 sheet (80 gsm)
Media sizes 8.5 x 14 in. (legal) 8.5 x 11 in. (A4), 5.5 x 8.5
i
n. (A5), A6, EXEC, ISO B5, JIS B5, Oficio,
Folio, Envelope (No 10, Monarch, DL, C5, C6)
Postcard 4x6, Custom
Media type Plain, Heavy-weight, Light-weight, Cotton,
Colored,
Pre-printed, Recycled, Envelope,
Transparency, Label, Cardstock, Bond,
Archive
Media weight 16 to 58 lb (60 to 216 gsm)
Sensing No
Output Tray Full sensing Ye s
Optional Cassette Tray N/A
Output Tray stacking capacity Face-down: 120 sheets (80 gsm)
Face-up: 1 sheet
Duplex (B215 only) Supporting Yes (Built-in)
Media sizes 8.5 x 14 in. (legal) 8.5 x 11 in. (A4), 5.5 x 8.5
i
n. (A5), A6, ISO B5, JIS B5, Executive, Oficio,
Folio, Custom
Media types Plain, Light-weight, Recycled, Heavy-weight,
Ar
chive
Media weight 16 to 28 lb (60 to 105 gsm)
Non-printable Area Envelope 0.4 in (10 mm) from edge
Other media 0.16 in (4 mm) from edge
Table 8 Toner Cartridge/Print Cartridge
Machine Model Item
B215/B205 Toner Cartridge - Starter 1k images (110VAC)
1.5k images (220VAC)
Toner Cartridge - Standard
106R04346 (NA/XE) CRU 1.5k images
Toner Cartridge - High Yield
106R04347 (NA/XE) CRU 3k images
Toner Cartridge
DMO -
106R04348 CRU
2 pk. - 106R04349 CRU
3k images
3k images ea. 6k images total
Drum Cartridge (Imaging
Unit
)
101R00664 CRU
10k images
Table 9 Reliability and Service
Item Specification B205 / B215
Printing Volume (SET AMPV) 250 - 400 pages
Maximum Monthly Duty 12,000 pages
MPBF 30,000 pages
MTTR 30 minutes
SET Life Cycle 100,000 pages or 5 years (whichever comes first)
Table 10 Environment
Item Specification B205 / B215
Operating Environment Temperature 50 - 90 F (10C to 32C)
Humidity 20% - 80%
Acoustic Noise Level
(Sound
Power/Pressure)
Print Less than 50 dB
Standby Less than 30 dB
Sleep Mode Back Ground Level
Power Consumption Print 500 W
Standby 55 W
Sleep Mode 1.4 W
Power Off 0.2 W
When Wi-fi Direct Mode off, 1.6 W
Dimension (W x D x H) SET 15.8 x 14.25 x 14.4 in.
(401 x 362 x 365.1 mm)

Xerox B205 Specifications

General

Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Booklet printing function	Yes
Time to first page (black, normal)	8.5 s
Print speed (black, normal quality, A4/US Letter)	30 ppm
Digital sender	-
Printing colors	Black
Country of origin	China
Maximum duty cycle	30000 pages per month
Number of print cartridges	1
Page description languages	PCL 5, PCL 6, PostScript 3, XPS
Maximum copy resolution	600 x 600 DPI
Time to first copy (black, normal)	14 s
Scan to	E-mail, FTP, SMB, USB
Scanner type	Flatbed & ADF scanner
Maximum scan area	216 x 356 mm
Image formats supported	JPG, TIFF
Maximum scan resolution	4800 x 4800 DPI
Document formats supported	PDF
Optical scanning resolution (black)	1200 x 1200 ppi
Display	LCD
Product color	Black, White
Market positioning	Business
Display number of lines	2 lines
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Cabling technology	10/100Base-T(X)
Ethernet LAN data rates	10, 100 Mbit/s
Mobile printing technologies	Apple AirPrint, Google Cloud Print, Mopria Print Service
USB connector	USB Type-A / USB Type-B
USB 2.0 ports quantity	2
Compatibility	Xerox B205
Internal memory	256 MB
Paper input type	Paper tray
Total input capacity	250 sheets
Total output capacity	120 sheets
Multi-Purpose tray input capacity	1 sheets
Auto document feeder (ADF) input capacity	40 sheets
Paper tray media weight	60 - 163 g/m²
Multi-purpose tray media types	Bond paper, Envelopes, Heavyweight paper, Labels, Plain paper, Preprinted forms, Thicker paper, Transparencies
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 220 g/m²
Auto Document Feeder (ADF) media weight	60 - 120 g/m²
Power consumption (standby)	46 W
Power consumption (PowerSave)	2 W
Power consumption (average operating)	417 W
Mac operating systems supported	Mac OS X 10.10 Yosemite, Mac OS X 10.11 El Capitan, Mac OS X 10.12 Sierra, Mac OS X 10.13 High Sierra, Mac OS X 10.14 Mojave, Mac OS X 10.9 Mavericks
Server operating systems supported	Windows Server 2008, Windows Server 2008 R2, Windows Server 2012, Windows Server 2012 R2, Windows Server 2016, Windows Server 2019
Windows operating systems supported	Windows 10, Windows 7, Windows 8
Cables included	USB
Included cartridge capacity (black)	1500 pages
Recommended monthly print volume	2500 pages
Package weight	13000 g
Operating temperature (T-T)	10 - 32 °C
Operating relative humidity (H-H)	20 - 80 %
Harmonized System (HS) code	84433100

Weight and Dimensions

Depth	430 mm
Width	490 mm
Height	480 mm
