Xerox® B205/B215 Multifunction Printer Service Manual
Diagnostic Information
General Procedures / Information
Initial Release
Diagnostic Information
Diagnostic Mode Menu - Data Setup
Purpose
This section of the Service Documentation contains information about Diagnostic Procedures.
This section also contains various other product-specific information that may be useful and/or
needed for servicing the machine.
To enter Diagnostics Mode, refer to GP
1, Entering and Exiting Diagnostics.
Table 1 Diagnostic Mode Menu - Data Setup
Level 1 Level 2 Level 3 Level 4 Level 5 Level 6 B205 B215
Data Setup Send Level India, Nepal and China - [0-15],
Other Countries - [9-15]
12
NA YES
DTMF Level (High) 0-15 (Low) 0-15 NA YES
Pause Time 1-9 NA YES
Dial Mode Tone NA YES
Pulse NA YES
Modem Speed 33.6 NA YES
28.8 NA YES
14.4 NA YES
12.0 NA YES
9.6 NA YES
4.8 NA YES
Error Rate 10% NA YES
5% NA YES
*Clear All Memory YES YES
Toner Low Level 1-50% YES YES
ImgU. Low Level 1-50% YES YES
Clear Counts Enter <1934> Fuser YES YES
Transfer Roller YES YES
Pickup Roller YES YES
Retard Roller YES YES
Forward Roller YES YES
ADF Roller YES YES
ADF Rubber Pad YES YES
Engine Footer Off
On
YES YES
Dial Tone On
Off
NA YES
