Xerox B205

July 2019
6-34
Xerox® B205/B215 Multifunction Printer Service Manual
(Diagnostics Mode)
Initial Release
General Procedures / Information
DC330 Component Control Codes
Purpose
Ta b l e 3 , provides component control codes for the purpose of troubleshooting components
within the machine.
Table 3 Component Control
Diagnostic
Co
de Chain Code Displayed on B215 UI Display on B205 LCD Definition BIT
Input/
Output State Displayed
Related
Component
04-100 100 Main BLDC Motor Main BLDC Main Feed (BLDC) Motor
is
On/Off
BIT_0 Output On[Off] Engine
04-110 100 Main BLDC Motor Ready Main BLDC Rdy Detect if Main Feed
(B
LDC) Motor runs at
normal speed
BIT_0 Input High[Low] Engine
06-100 110 LSU Motor1 Run LSU Motor1 Run LSU Motor1 On/Off BIT_10 Output On[Off] Engine
06-110 110 LSU Motor1 Rdy LSU Motor1 Rdy Detects if LSU motor1
r
uns at normal speed
BIT_12 Input High[Low] Engine
06-200 110 LSU LD Power4 LSU LD Power4 LSU LD4 Power On/Off
(b
lack)
BIT_11 Output On[Off] Engine
06-400 110 LSU HSync4 LSU HSync4 Horizontal Sync Input High[Low] Engine
07-110 102 T1 Paper Empty Sensor Tray 1 Empty Detects when a sheet is
in T
ray1
BIT_16 Input High[Low] Engine
08-100 102 Feed Sens Feed Sens Detects when a sheet is
at
Feed sensor
BIT_7 Input High[Low] Engine
08-500 102 Regi Sens Regi Sens Detects when a sheet is
at
registration sensor
BIT_6 Input High[Low] Engine
08-600 102 Exit Sens Exit Sens Detects when a sheet is
at
Exit sensor
BIT_11 Input High[Low] Engine
08-720 101 Out-Bin Full Sensor Out Bin Full Detects when the output
t
ray is full
BIT_14 Output High[Low] Engine
08-810 101 T1 Pick up Clutch Tray1 Pickup Engages drive to pick up
a p
aper from tray1.
BIT_13 Output On[Off] Engine
08-850 101 Registration Clutch Registration Engages drive to regis-
tration rolls
BIT_15 Output On[Off] Engine
09-100 105 Black MHV Bias
K MHV Bias Black MHV bias voltage
on at normal drive level
BIT_24 Output On[Off] Engine
09-200 106 Black Dev Bias K Dev Bias Black Dev bias voltage
on at
normal drive level
BIT_25 Output On[Off] Engine
09-300 107 Black THV Bias K THV Bias Black THV bias voltage
on at
normal drive level
Input On[Off] Engine
09-310 107 Black THV Bias Read K THV(-) BiasR Black THV bias voltage Numeric 3 digits Engine
09-400 107 Black THV(-) Bias K THV(-) Bias Black THV bias voltage
on at
normal drive level
Input On[Off] Engine
10-200 109 Fuser Temperature A Te m p A Detects what the temper-
ature A is on fuser.
Input Numeric 3 digits Engine
