Xerox B205 Service Manual

July 2019
2-11
Xerox® B205/B215 Multifunction Printer Service Manual
07-130 , 07-500
Status Indicator RAPs
Initial Release
YN
Check that all voltages are present between the HVPS PWB and the Main
PWB
. The voltages between the HVPS PWB and the Main PWB are
pr
esent.
YN
• Install a new HVPS PWB, PL 4.
1 I
tem 2.
• Install a new Main PWB, PL 1.
1 Item 4.
Install a new Paper Feed Sensor PWB, P
L 4.4 Item 20.
Install a new Paper Feed Sensor PWB, PL
4.4 Item 20.
Install a new Paper Feed Sensor PWB, PL
4.4 Item 20.
In Diagnostics Mode, go to [101-Cl
utch, Tray 1 Pick up] to energize the clutch. The
clutch engages.
YN
Check for 24VDC on the Paper Feed PWB. The voltage is present at the connec-
tor on the Paper Feed PWB.
YN
Check that all voltages are present between the HVPS PWB and the Main
PW
B
. The voltages between the HVPS PWB and the Main PWB are pres-
ent.
YN
• Install a new HVPS PWB, PL 4.
1 I
tem 2.
• Install a new Main PWB, PL 1.1 I
tem 4.
Install a new Paper Feed PWB, PL 4.1 I
tem 15.
Install a new Feed Clutch, PL 4.1 I
tem 5.
Perform SCP Final Actions.
Remove any jammed paper. Check the following for wear or damage and replace as required:
• Retard Roll, PL 4.
5 Item 15.
• Paper Feed Roll Assembly, PL
4.5 Item 11.
• Earth Transfer Plate, PL 4.4 Item 1.
•
Earth Transfer Plate Springs, PL
4.4 Item 3 and PL 4.4 Item 7.
07-500 Manual Feed Slot Paper Empty RAP
BSD-ON:BSD 1
Control Panel Fault Displayed
B205: Bypass Empty
B215: Bypass Tray is Out of Paper
The Manual Feed Slot Empty Sensor failed to detect paper in the Manual Feed Slot.
Initial Actions
Ensure that paper is loaded in the tray. Clear any jammed sheets. (Refer to Section 11 in the
Xerox® B215/B205 User Guide for detailed instructions on jam clearance.)
WARNING
Do not perform repair activities with the power on or electrical power supplied to the
machine. The machine could activate and cause serious personal injury when the power
is on or electrical power is supplied.
DANGER: Ne pas effectuer de dépannage avec le contact principal activé ou avec l'ali-
mentation électrique appliquée à la machine: celle-ci pourrait démarrer et causer de
g
ra
ves blessures.
AVVERTENZA: Non effettuare alcuna riparazione con la macchina accesa o con l'ali-
mentazione elettrica inserita. La macchina potrebbe avviarsi all'improvviso e causare
gr
a
vi ferite.
VORSICHT: Es dürfen keine Reparaturarbeiten durchgeführt werden, solange das Gerät
ein
geschalten oder mit der Stromquelle verbunden ist. Das Gerät kann u.U in den Aktiv-
Zustand übergehen und somit erhebliche körperliche Schäden verursachen.
AVISO: No realice reparaciones con la máquina encendida o conectada a la corriente.
L
a
máquina podría activarse y ocasionar daños personales graves.
Procedure
Check the Registration Sensor actuator. The actuator moves freely and is undamaged.
YN
Install a new Registration Sensor Actuator, P
L 4.
4 Item 19.
Enter Diagnostics Mode, Select [M
achine Test, Diagnostics Mode, DC330 Component
Control, 102-Sensor, Registration Sensor} to block and clear the Registration Sensor. The
senso
r signal changes.
YN
Check for 3.3VDC on the Main PWB. The voltage is present on the Main PWB.
YN
• Install a new HVPS PWB, PL
4.
1 Item 2.
• Install a new Main PWB, PL 1.
1 Item 4.
Install a new Paper Feed Sensor PWB, PL PL 4.
4 Item 20.
Perform SCP Final Actions.
A B C

Xerox B205 Specifications

General

Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Booklet printing function	Yes
Time to first page (black, normal)	8.5 s
Print speed (black, normal quality, A4/US Letter)	30 ppm
Digital sender	-
Printing colors	Black
Country of origin	China
Maximum duty cycle	30000 pages per month
Number of print cartridges	1
Page description languages	PCL 5, PCL 6, PostScript 3, XPS
Maximum copy resolution	600 x 600 DPI
Time to first copy (black, normal)	14 s
Scan to	E-mail, FTP, SMB, USB
Scanner type	Flatbed & ADF scanner
Maximum scan area	216 x 356 mm
Image formats supported	JPG, TIFF
Maximum scan resolution	4800 x 4800 DPI
Document formats supported	PDF
Optical scanning resolution (black)	1200 x 1200 ppi
Display	LCD
Product color	Black, White
Market positioning	Business
Display number of lines	2 lines
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Cabling technology	10/100Base-T(X)
Ethernet LAN data rates	10, 100 Mbit/s
Mobile printing technologies	Apple AirPrint, Google Cloud Print, Mopria Print Service
USB connector	USB Type-A / USB Type-B
USB 2.0 ports quantity	2
Compatibility	Xerox B205
Internal memory	256 MB
Paper input type	Paper tray
Total input capacity	250 sheets
Total output capacity	120 sheets
Multi-Purpose tray input capacity	1 sheets
Auto document feeder (ADF) input capacity	40 sheets
Paper tray media weight	60 - 163 g/m²
Multi-purpose tray media types	Bond paper, Envelopes, Heavyweight paper, Labels, Plain paper, Preprinted forms, Thicker paper, Transparencies
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 220 g/m²
Auto Document Feeder (ADF) media weight	60 - 120 g/m²
Power consumption (standby)	46 W
Power consumption (PowerSave)	2 W
Power consumption (average operating)	417 W
Mac operating systems supported	Mac OS X 10.10 Yosemite, Mac OS X 10.11 El Capitan, Mac OS X 10.12 Sierra, Mac OS X 10.13 High Sierra, Mac OS X 10.14 Mojave, Mac OS X 10.9 Mavericks
Server operating systems supported	Windows Server 2008, Windows Server 2008 R2, Windows Server 2012, Windows Server 2012 R2, Windows Server 2016, Windows Server 2019
Windows operating systems supported	Windows 10, Windows 7, Windows 8
Cables included	USB
Included cartridge capacity (black)	1500 pages
Recommended monthly print volume	2500 pages
Package weight	13000 g
Operating temperature (T-T)	10 - 32 °C
Operating relative humidity (H-H)	20 - 80 %
Harmonized System (HS) code	84433100

Weight and Dimensions

Depth	430 mm
Width	490 mm
Height	480 mm
