Xerox B205 Service Manual

July 2019
2-24
Xerox® B205/B215 Multifunction Printer Service Manual
15-400 , 15-410, 15-420
Initial Release
Status Indicator RAPs
15-400 LDAP Communication Failure RAP
BSD-ON:BSD 1
Control Panel Fault Displayed
B205: NA
B215: LDAP Communication Error
The machine is unable to contact the LDAP server.
WARNING
Do not perform repair activities with the power on or electrical power supplied to the
machine. The machine could activate and cause serious personal injury when the power
is on or electrical power is supplied.
DANGER: Ne pas effectuer de dépannage avec le contact principal activé ou avec l'ali-
mentation électrique appliquée à la machine: celle-ci pourrait démarrer et causer de
g
raves blessures.
AVVERTENZA: Non effettuare alcuna riparazione con la macchina accesa o con l'ali-
mentazione elettrica inserita. La macchina potrebbe avviarsi all'improvviso e causare
gr
avi ferite.
VORSICHT: Es dürfen keine Reparaturarbeiten durchgeführt werden, solange das Gerät
ei
ngeschalten oder mit der Stromquelle verbunden ist. Das Gerät kann u.U in den Aktiv-
Zustand übergehen und somit erhebliche körperliche Schäden verursachen.
AVISO: No realice reparaciones con la máquina encendida o conectada a la corriente.
L
a máquina podría activarse y ocasionar daños personales graves.
Procedure
Printers using ethernet connection: The ethernet connection is good.
YN
Connect the printer to the ethernet port connection.
Verify the ethernet connection is active and network services; Internet and other network
ser
vices or devices are working.
Printers using WiFi: check the CN1 connector between the WiFi PWB, P
L 1.1 Item 10, and the
Main PWB, PL 1.1 Item 4. The connector is fully seated.
YN
• Check for contamination or obstruction in the connector.
• Disconnect, then reconnect the connector.
• If the fault persist, install a new WiFi PWB, P
L 1.1 Item 10.
Perform the following checks:
• Check the LDAP IP address or Host Name.
• Check the LDAP port is open and connected.
15-410, 15-420 LDAP Search Failure RAP
Control Panel Fault Displayed
15-410 LD
AP server returned an error during transmission.
B205: NA
B215: LDAP Search Error
15-420
Displays when LDAP search timeout has execeeded parameter.
B205: NA
B215: LDAP Time Limit has been Exceeded
The LDAP server returned an error during transmission.
Initial Actions
• Ensure that the LDAP server is enabled on the device and that maximum search results
ha
ve not been exceeded.
• Check if the LDAP search has e
xceeded time limit parameters.
Procedure
Resubmit the job. If problem persists, contact Email administrator.

Xerox B205 Specifications

General

Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Booklet printing function	Yes
Time to first page (black, normal)	8.5 s
Print speed (black, normal quality, A4/US Letter)	30 ppm
Digital sender	-
Printing colors	Black
Country of origin	China
Maximum duty cycle	30000 pages per month
Number of print cartridges	1
Page description languages	PCL 5, PCL 6, PostScript 3, XPS
Maximum copy resolution	600 x 600 DPI
Time to first copy (black, normal)	14 s
Scan to	E-mail, FTP, SMB, USB
Scanner type	Flatbed & ADF scanner
Maximum scan area	216 x 356 mm
Image formats supported	JPG, TIFF
Maximum scan resolution	4800 x 4800 DPI
Document formats supported	PDF
Optical scanning resolution (black)	1200 x 1200 ppi
Display	LCD
Product color	Black, White
Market positioning	Business
Display number of lines	2 lines
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Cabling technology	10/100Base-T(X)
Ethernet LAN data rates	10, 100 Mbit/s
Mobile printing technologies	Apple AirPrint, Google Cloud Print, Mopria Print Service
USB connector	USB Type-A / USB Type-B
USB 2.0 ports quantity	2
Compatibility	Xerox B205
Internal memory	256 MB
Paper input type	Paper tray
Total input capacity	250 sheets
Total output capacity	120 sheets
Multi-Purpose tray input capacity	1 sheets
Auto document feeder (ADF) input capacity	40 sheets
Paper tray media weight	60 - 163 g/m²
Multi-purpose tray media types	Bond paper, Envelopes, Heavyweight paper, Labels, Plain paper, Preprinted forms, Thicker paper, Transparencies
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 220 g/m²
Auto Document Feeder (ADF) media weight	60 - 120 g/m²
Power consumption (standby)	46 W
Power consumption (PowerSave)	2 W
Power consumption (average operating)	417 W
Mac operating systems supported	Mac OS X 10.10 Yosemite, Mac OS X 10.11 El Capitan, Mac OS X 10.12 Sierra, Mac OS X 10.13 High Sierra, Mac OS X 10.14 Mojave, Mac OS X 10.9 Mavericks
Server operating systems supported	Windows Server 2008, Windows Server 2008 R2, Windows Server 2012, Windows Server 2012 R2, Windows Server 2016, Windows Server 2019
Windows operating systems supported	Windows 10, Windows 7, Windows 8
Cables included	USB
Included cartridge capacity (black)	1500 pages
Recommended monthly print volume	2500 pages
Package weight	13000 g
Operating temperature (T-T)	10 - 32 °C
Operating relative humidity (H-H)	20 - 80 %
Harmonized System (HS) code	84433100

Weight and Dimensions

Depth	430 mm
Width	490 mm
Height	480 mm
