Xerox® B210 Service Manual
Product Specifications
Initial Release
General Procedures - Information
NOTE: ** Declared yield value in accordance with ISO/IEC 19752.
Depending on the options and job mode used, the toner cartridge’s lifespan may differ.
When replacing a Toner/Print Cartridge, check model number and consumables code. Refer to
t
he Xerox® B210 User Guide for information regarding ordering consumables.
Manual Feeder Capacity 1 Sheet
Media Size 8.5 x 11 in. (letter), 8.5 x 14 in. (legal), A4, A5, A6,
Ex
ecutive, Oficio, Folio, ISO B5, JIS B5, Envelope:
(No 10, Monarch, DL, C5, C6), Custom: 3 x 5 in. thru
8.5 x 14 in. (76mm x 127mm to 216 x 356 mm)
Media Type Plain, Light-weight, Heavy-weight, Cardstock,
T
ransparency, Pre-printed, Recycled, Archive,
Bond, Label, Envelope, Heavy-weight Envelope,
Cotton, Colored
Media Weight 16 to 58 lb (60 to 220 gsm)
Sensing Ye s
Table 5 Toner Cartridge/Print Cartridge
Machine Model Item
B210 Toner Cartridge - Starter 1k images (110VAC)
1.5k images (220VAC)
Toner Cartridge - Standard
106R04346 (NA/XE) CRU 1.5k images
Toner Cartridge - High Yield
106R04347 (NA/XE) CRU 3k images
Toner Cartridge
DMO -
106R04348 CRU
2 Pk - 106R04349 CRU
3k images
3k images ea. 6k images total
Drum Cartridge (Imaging Unit)
101R00664 CRU 10k images
Table 6 Reliability and Service
Item Specification
Printing Volume (SET AMPV) 250 - 400 pages
Maximum Monthly Duty 12,000 pages
MPBF 30,000 pages
MTTR 30 minutes
SET Life Cycle 100,000 pages or 5 years (whichever comes first)
Table 4 Paper Handling Specifications
I
tem Specification
Table 7 Environment
Item Specification
Acoustic Noise
Le
vel
Printing (Simplex) Less than 50 dB
Standby Less than 26 dB
Sleep Mode Less than 26 dB
Power Consumption Ready Less than 45 W
Normal Operation Less than 400 W
Max/Peak Less than 450 W
Sleep Less than 0.9 W
Power Off Less than 0.2 W
TEC Less than 1.1 kWh per week
Certification Telecommunication TBR-21, KC, Part68, ICCS03,
CE
(EN), KCC
Safety cUL, CB, KC, TUV-GS, PSB
EMC/EMI FCC Part 15 Class B, ICES003,
CE
(EN), KCC
Document No
Security No
Others No
Dimension
(W x D x H)
SET 14.5 x 13.2 x 8.0 in.
(368 x 334.5 x 202 mm)
SET Packing (452 x 418 x 330 mm)
17.8 x 16.5 x 13.0 in.
Weight Net (SET without consumables) 3.8 lbs (6.3 kg)
Net (SET with consumables) 7.2 lbs (6.3 kg)
Gross (SET with packaging) 9.1 lbs (20.1 kg)
Consumable
(wit
hout pack-
aging)
Toner Cartridge 1.2K: 1.10 lbs (0.50 kg)
3.0K: 1.19 lbs. (0.54 kg)
Imaging Unit 0.84 lbs. (0.38 kg)

Xerox B210 Specifications

General

Color	No
Duplex printing	Yes
Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Time to first page (black, normal)	8.5 s
Print speed (black, normal quality, A4/US Letter)	30 ppm
Printing colors	Black
Country of origin	China
Maximum duty cycle	30000 pages per month
Number of print cartridges	1
Page description languages	PCL 5, PCL 6, PostScript 3, XPS
Paper input type	Paper tray
Total input capacity	250 sheets
Total output capacity	120 sheets
Multi-Purpose tray input capacity	1 sheets
Custom media width	105 - 216 mm
Maximum print size	216 x 356 mm
Custom media length	149 - 356 mm
Paper tray media types	-
Paper tray media weight	60 - 163 g/m²
Multi-purpose tray media types	Bond paper, Envelopes, Heavyweight paper, Labels, Plain paper, Preprinted forms, Thicker paper, Transparencies
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 220 g/m²
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Cabling technology	10/100Base-T(X)
Ethernet LAN data rates	10, 100 Mbit/s
Mobile printing technologies	Apple AirPrint, Google Cloud Print, Mopria Print Service
USB connector	USB Type-B
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Internal memory	256 MB
Processor frequency	600 MHz
Maximum internal memory	- MB
Sound pressure level (printing)	- dB
Sustainability certificates	ENERGY STAR
Certification	EPEAT
Product color	Black, White
Market positioning	Business
Power consumption (standby)	46 W
Power consumption (printing)	- W
Power consumption (PowerSave)	2 W
Mac operating systems supported	Mac OS X 10.10 Yosemite, Mac OS X 10.11 El Capitan, Mac OS X 10.12 Sierra, Mac OS X 10.13 High Sierra, Mac OS X 10.14 Mojave, Mac OS X 10.9 Mavericks
Server operating systems supported	Windows Server 2008, Windows Server 2008 R2, Windows Server 2012, Windows Server 2012 R2, Windows Server 2016, Windows Server 2019
Windows operating systems supported	Windows 10, Windows 7, Windows 8
Package weight	10000 g
Cables included	AC
Included cartridge capacity (black)	1500 pages
Compatibility	Xerox B210
Recommended monthly print volume	4000 pages
Operating temperature (T-T)	10 - 32 °C
Operating relative humidity (H-H)	20 - 80 %
Harmonized System (HS) code	84433210

Weight and Dimensions

Depth	420 mm
Width	460 mm
Height	350 mm
Weight	7560 g
