July 2019
4-29
Xerox® B210 Service Manual
REP 4.10, REP 4.11
Repairs - Adjustments
Initial Release
Replacement
Replacement is the reverse of the removal procedure.
NOTE: Tapered plastic screws and round machine screws are used to hold the cover to the
f
rame. Make sure that the plastic screws go into plastic components and machine screws go
into the metal frame.
REP 4.11 Manual Paper Tray
Parts List on PL 4.4
Removal
1. Switch Off the Printer and unplug the Power Cord.
2. Remove the Top Cover, RE
P 3.2.
3. Remove two screws securing the bottom of the Manual Paper Tray, Figure 1.
Figure 1 Manual Paper Tray Bottom Screws (Bottom View)
To Next Page
