July 2019
3-11
Xerox® B210 Service Manual
IQ12
Image Quality
Initial Release
IQ12 Partial Image Deletions RAP
Areas of the printed image are light or missing entirely on limited areas of the paper, Figure 1.
Initial Actions
Be sure the printer is installed on a level surface.
Procedure
Procedure
• Switch off the machine.
• Remove the Toner Cartridge.
• Rotate the Toner Cartridge side to side for 5 to 6 full rotations to redistribute the toner.
• Reinstall the Toner Cartridge and print 10 test copies.
The problem continues.
YN
Perform SC
P 04, Final Actions.
Switch off the machine.
Check the Transfer Roll P
L 4.1 Item 10, for the following:
• Wear or damage.
• The left and right tension springs for damage.
• Verify all parts are installed correctly.
Figure 1 Image Deletions
To Next Page
