Xerox B210 Service Manual

July 2019
3-6
Xerox® B210 Service Manual
IQ5, IQ6
Initial Release
Image Quality
IQ5 Low Image Density RAP
The printed image is light, with no ghosting, Figure 1.
Initial Actions
Remove Toner Cartridge. Rotate the cartridge 5-6 full rotations to redistribute the toner. Make a
test print.
Check the life of the Toner Cartridge, refer to GP 2,
Machine Reports. Install a new Toner Car-
tridge if it has reached end of life.
If the problems continue, follow the procedure.
Procedure
• Switch off the machine.
• Clean the contacts on the Print Cartridge and the HVPS PWB.
• Switch on the power, then make a test print.
The problem continues.
YN
Perform SC
P 04, Final Actions.
Install a new HVPS PWB, PL 4.
1 Item 2.
Figure 1 Light Image
IQ6 Black or Dark Image RAP
The printed image is totally dark or black, Figure 1.
Procedure
WARNING
Do not perform repair activities with the power on or electrical power supplied to the
machine. Some machine components contain dangerous electrical voltages that can
result in electrical shock and possible serious injury.
DANGER: Ne pas effectuer de dépannnage avec le contact principal activé ou avec l'ali-
mentation électrique appliquée à la machine. Certains éléments de la machine compor-
tent des tensions électriques dangereuses qui peuvent causer un choc électrique et de
g
raves blessures.
AVVERTENZA: Non effettuare alcuna riparazione con l'alimentazione elettrica inserita.
Alc
uni componenti contengono corrente ad alta tensione che può provocare forti
scosse e gravi ferite.
VORSICHT: Es dürfen erst Reparaturarbeiten durchgeführt werden, wenn das Gerät aus-
geschaltet ist oder der Netzstecker nicht mehr mit der Stromquelle verbunden ist. Einige
K
omponenten des Gerätes sind stromführend und können daher zu ernsthaften Verlet-
zungen oder Stromschlägen führen.
AVISO: No realice reparaciones con la máquina encendida o conectada a la corriente.
Alg
unos componentes de la máquina contienen voltajes eléctricos peligrosos que
pueden producir una descarga eléctrica y causar daños graves.
• Switch off the machine.
• Clean the contacts on the Toner Cartridge, Drum Cartridge, and the HVPS PWB, PL 4.
1
It
em 2
.
• Switch on the power, then make a test print.
The problem continues.
YN
Perform SC
P 04, Final Actions.
• If the image is Black, install a new HVPS PWB, P
L 4.1 Item 2, switch on the power, then
mak
e a test print.

Xerox B210 Specifications

General

Color	No
Duplex printing	Yes
Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Time to first page (black, normal)	8.5 s
Print speed (black, normal quality, A4/US Letter)	30 ppm
Printing colors	Black
Country of origin	China
Maximum duty cycle	30000 pages per month
Number of print cartridges	1
Page description languages	PCL 5, PCL 6, PostScript 3, XPS
Paper input type	Paper tray
Total input capacity	250 sheets
Total output capacity	120 sheets
Multi-Purpose tray input capacity	1 sheets
Custom media width	105 - 216 mm
Maximum print size	216 x 356 mm
Custom media length	149 - 356 mm
Paper tray media types	-
Paper tray media weight	60 - 163 g/m²
Multi-purpose tray media types	Bond paper, Envelopes, Heavyweight paper, Labels, Plain paper, Preprinted forms, Thicker paper, Transparencies
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 220 g/m²
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Cabling technology	10/100Base-T(X)
Ethernet LAN data rates	10, 100 Mbit/s
Mobile printing technologies	Apple AirPrint, Google Cloud Print, Mopria Print Service
USB connector	USB Type-B
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Internal memory	256 MB
Processor frequency	600 MHz
Maximum internal memory	- MB
Sound pressure level (printing)	- dB
Sustainability certificates	ENERGY STAR
Certification	EPEAT
Product color	Black, White
Market positioning	Business
Power consumption (standby)	46 W
Power consumption (printing)	- W
Power consumption (PowerSave)	2 W
Mac operating systems supported	Mac OS X 10.10 Yosemite, Mac OS X 10.11 El Capitan, Mac OS X 10.12 Sierra, Mac OS X 10.13 High Sierra, Mac OS X 10.14 Mojave, Mac OS X 10.9 Mavericks
Server operating systems supported	Windows Server 2008, Windows Server 2008 R2, Windows Server 2012, Windows Server 2012 R2, Windows Server 2016, Windows Server 2019
Windows operating systems supported	Windows 10, Windows 7, Windows 8
Package weight	10000 g
Cables included	AC
Included cartridge capacity (black)	1500 pages
Compatibility	Xerox B210
Recommended monthly print volume	4000 pages
Operating temperature (T-T)	10 - 32 °C
Operating relative humidity (H-H)	20 - 80 %
Harmonized System (HS) code	84433210

Weight and Dimensions

Depth	420 mm
Width	460 mm
Height	350 mm
Weight	7560 g
