Xerox B210 Service Manual

July 2019
3-10
Xerox® B210 Service Manual
IQ11
Initial Release
Image Quality
IQ11 Blank Page RAP
The entire image area is blank, Figure 1.
Initial Actions
Install new components at end of life, refer to GP 2, Machine Reports.
Procedure
• Switch off the machine.
• Check the space between the LSU PL 4.
1 Item 22, and the Drum Cartridge, remove any
debr
is or blockage.
• Clean the terminals on the Toner Cartridge and the HVPS PWB, PL 4.
1 Item 2.
• Switch on the power, then make a test print.
The problem continues.
YN
Perform SCP 04, Final Actions.
Install a new Drum Cartridge, refer to the Xerox® B210 User Guide, Section 6 Maintenance,
G
eneral Care, for detailed instructions on how to Install a new Drum Cartridge. The problem
co
ntinues.
YN
Perform SCP 04, Final Actions.
Check the circuit between the Main PWB, P
L 1.1 Item 7 and the HVPS PWB, PL 4.1 Item 2.
The circuit is OK.
YN
Install new components as required:
• Main PWB to LVPS / HVPS PWB Wire Harness.
• Main PWB, P
L 1.1 Item 7.
• HVPS PWB, PL 4.1 Item 2.
Perform SCP 04, Final Actions.
Figure 1 Blank Image

Xerox B210 Specifications

General

Color	No
Duplex printing	Yes
Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Time to first page (black, normal)	8.5 s
Print speed (black, normal quality, A4/US Letter)	30 ppm
Printing colors	Black
Country of origin	China
Maximum duty cycle	30000 pages per month
Number of print cartridges	1
Page description languages	PCL 5, PCL 6, PostScript 3, XPS
Paper input type	Paper tray
Total input capacity	250 sheets
Total output capacity	120 sheets
Multi-Purpose tray input capacity	1 sheets
Custom media width	105 - 216 mm
Maximum print size	216 x 356 mm
Custom media length	149 - 356 mm
Paper tray media types	-
Paper tray media weight	60 - 163 g/m²
Multi-purpose tray media types	Bond paper, Envelopes, Heavyweight paper, Labels, Plain paper, Preprinted forms, Thicker paper, Transparencies
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 220 g/m²
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Cabling technology	10/100Base-T(X)
Ethernet LAN data rates	10, 100 Mbit/s
Mobile printing technologies	Apple AirPrint, Google Cloud Print, Mopria Print Service
USB connector	USB Type-B
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Internal memory	256 MB
Processor frequency	600 MHz
Maximum internal memory	- MB
Sound pressure level (printing)	- dB
Sustainability certificates	ENERGY STAR
Certification	EPEAT
Product color	Black, White
Market positioning	Business
Power consumption (standby)	46 W
Power consumption (printing)	- W
Power consumption (PowerSave)	2 W
Mac operating systems supported	Mac OS X 10.10 Yosemite, Mac OS X 10.11 El Capitan, Mac OS X 10.12 Sierra, Mac OS X 10.13 High Sierra, Mac OS X 10.14 Mojave, Mac OS X 10.9 Mavericks
Server operating systems supported	Windows Server 2008, Windows Server 2008 R2, Windows Server 2012, Windows Server 2012 R2, Windows Server 2016, Windows Server 2019
Windows operating systems supported	Windows 10, Windows 7, Windows 8
Package weight	10000 g
Cables included	AC
Included cartridge capacity (black)	1500 pages
Compatibility	Xerox B210
Recommended monthly print volume	4000 pages
Operating temperature (T-T)	10 - 32 °C
Operating relative humidity (H-H)	20 - 80 %
Harmonized System (HS) code	84433210

Weight and Dimensions

Depth	420 mm
Width	460 mm
Height	350 mm
Weight	7560 g
