July 2019
7-4
Xerox® B210 Service Manual
Initial Release
BSD
BSD 1
1.1 - Main/Power/Electrical/Drive/Fuser/Networking/LSU/CRUM
Figure 1 BSD 1.1 - Main/ADF/Power/Electrical/Drive/Fuser/Networking/LSU/CRUM
