Xerox WorkCentre 3345 Service Manual

Troubleshooting
Xerox Internal Use Only Phaser 3330 and WorkCentre 3335/3345
Service Manual
2-95
07-100 Tray 1 Home Position Open
07-110 T1 Paper Empty Sensor Low
07-120 T1 Size1 Sensor Low (Off)
07-130 T1 Size2 Sensor Low (Off)
07-140 T1 Size3 Sensor Low (Off)
07-150 T1 Stack Height Sensor Low (Off)
07-160 T1 Paper Low Sensor Low (Off)
07-200 Tray2 Home Position Open (Off)
07-210 T2 Paper Empty Sensor Low (Off)
07-220 T2 Size1 Sensor Low (Off)
07-230 T2 Size2 Sensor Low (Off)
07-240 T2 Size3 Sensor Low (Off)
07-250 T2 Stack Height Sensor Low (Off)
07-260 T2 Paper Low Sensor Low (Off)
07-300 Tray3 Home Position Open (Off)
07-310 T3 Paper Empty Sensor Low (Off)
07-320 T3 Size1 Sensor Low (Off)
07-330 T3 Size2 Sensor Low (Off)
07-340 T3 Size3 Sensor Low (Off)
07-350 T3 Stack Height Sensor Low (Off)
07-360 T3 Paper Low Sensor Low (Off)
07-400 Tray4 Home Position Open (Off)
07-410 T4 Paper Empty Sensor Low (Off)
07-420 T4 Size1 Sensor Low (Off)
07-430 T4 Size2 Sensor Low (Off)
07-440 T4 Size3 Sensor Low (Off)
07-450 T4 Stack Height Sensor Low (Off)
07-460 T4 Paper Low Sensor Low (Off)
07-510 Bypass Paper Empty Sensor High (Off)
08-100 Feed Sensor Low (Off)
08-200 T2 Feed Sensor (or Door Open) Low (Off)
08-300 T3 Feed Sensor (or Door Open) Low (Off)
08-400 T4 Feed Sensor (or Door Open) Low (Off)
08-500 Regi Sensor Low (Off)
08-600 Fuser Exit Sensor Low (Off)
Chain-Link Component Name State (Default)

Xerox WorkCentre 3345 Specifications

General

Print Technology	Laser
Print Speed	Up to 42 ppm
Print Resolution	Up to 600 x 600 dpi
Automatic Document Feeder	50 sheets
Duplex Printing	Yes
Monthly Duty Cycle	Up to 80, 000 pages
First Page Out Time (Black)	As fast as 6.5 seconds
Processor	600 MHz
Paper Input (Standard)	250 sheets
Paper Output	150 sheets
Scan Resolution (Optical)	Up to 600 x 600 dpi
Fax Speed	33.6 Kbps
Copy Resolution	Up to 600 x 600 dpi
Connectivity	USB, Ethernet, Wi-Fi
Functions	Copy, Print, Scan, Fax, Email
Mobile Printing	Apple AirPrint, Google Cloud Print, Xerox Print Service Plugin for Android, Mopria
Media Sizes Supported	Letter, Legal, A4, A5, B5, A6
Fax Transmission Speed	3 seconds per page
Maximum Paper Size	216 x 356 mm
Copy Speed (Black)	Up to 42 cpm
