General Information
Xerox Internal Use Only Phaser 3330 and WorkCentre 3335/3345
Service Manual
1-13
Phaser 3330 Rear and Side Views
No. Description No. Description
1. Tray 1 Rear Access Cover 5. USB Cable Port
2. Power Receptacle 6. Network Cable Port
3. Power Switch 7. Duplex Assembly
4. 5V Output (Not Used) 8. Rear Door
