Xerox WorkCentre 3345 Service Manual

Troubleshooting
Phaser 3330 and WorkCentre 3335/3345 Xerox Internal Use Only
Service Manual
2-94
dC330 Component Control
Chain-Link Component Name State (Default)
01-100 Slide Cover Intlk Open
01-200 Exit Cover Present Sensor Not Present
04-100 Main BLDC Rdy Off
04-110 Low
04-120 Main Fan Off
04-200 Exit Mtr Fwd Fast Off
04-210 Exit Mtr Fwd Slow Off
04-220 Exit Mtr Rev Off
04-230 Dup Mtr Fwd Off
04-310 Dup MtrRev Off
04-400 Dup Fan Run Off
04-410 Dup Fan1 Run Rdy Low
04-420 Dup Fan2 Run Rdy Low
04-510 T1 Elev Mtr Off
04-520 T2 Elev Mtr Off
04-530 T3 Elev Mtr Off
04-540 T4 Elev Mtr Off
05-100 DADF Document Defect Sensor Off
05-120 DADF Paper Length Sensor Off
05-130 DADF Registration Sensor Off
05-140 Scan Sensor Off
05-160 DADF Door Open Sensor Off
05-200 DADF Scan Motor Forward Off
05-201 DADF Scan Motor Reverse Off
06-100 LSU Motor Run Off
06-110 LSU Motor Rdy Off
06-200 LSU LD Power Off
06-300 LSU Fan Run Off
06-310 LSU Fan Run Rdy Off

Xerox WorkCentre 3345 Specifications

General

Print Technology	Laser
Print Speed	Up to 42 ppm
Print Resolution	Up to 600 x 600 dpi
Automatic Document Feeder	50 sheets
Duplex Printing	Yes
Monthly Duty Cycle	Up to 80, 000 pages
First Page Out Time (Black)	As fast as 6.5 seconds
Processor	600 MHz
Paper Input (Standard)	250 sheets
Paper Output	150 sheets
Scan Resolution (Optical)	Up to 600 x 600 dpi
Fax Speed	33.6 Kbps
Copy Resolution	Up to 600 x 600 dpi
Connectivity	USB, Ethernet, Wi-Fi
Functions	Copy, Print, Scan, Fax, Email
Mobile Printing	Apple AirPrint, Google Cloud Print, Xerox Print Service Plugin for Android, Mopria
Media Sizes Supported	Letter, Legal, A4, A5, B5, A6
Fax Transmission Speed	3 seconds per page
Maximum Paper Size	216 x 356 mm
Copy Speed (Black)	Up to 42 cpm
