Xerox WorkCentre 3345 Service Manual

General Information
Phaser 3330 and WorkCentre 3335/3345 Xerox Internal Use Only
Service Manual
1-38
Paper Handling
Item Phaser 3330 WorkCentre 3335/3345
Standard Capacity 250-sheet Cassette Tray, 50-sheet
Multi Purpose Tray @80g/m
2
250-sheet Cassette Tray, 50-sheet
Multi Purpose Tray @80g/m
2
Max. Capacity (with Optional Tray)
850 sheets @80g/m
2
850 sheets @80g/m
2
Printing Max. Size 216 x 356 mm (8.5" x 14") 216 x 356 mm (8.5" x 14")
Min. Size 76 x 127 mm (3.0" x 5.0") 76 x 127 mm (3.0" x 5.0")
Bypass Tray
Capacity Plain Paper
50 sheets @80 g/m
2
50 sheets @80 g/m
2
Envelope 5 sheets 5 sheets
Media sizes A4, A5, A6, Letter, Legal, Folio,
Office, Executive, ISO B5, JIS B5,
3"x5", Envelope (Monarch, No.10,
DL, C5, C6), Custom
A4, A5, A6, Letter, Legal, Folio,
Oficio, Executive, ISO B5, JIS B5,
3"x5", Envelope (Monarch, No.10,
DL, C5, C6), Custom
Media Type Plain, Thin, Thick, Thicker, Cotton,
Colored, Envelope, Transparency,
Pre-Printed, Recycled, Labels,
Bond, Card stock, Archive
Plain, Thin, Thick, Thicker, Cotton,
Colored, Envelope, Transparency,
Pre-Printed, Recycled, Labels,
Bond, Card stock, Archive
Media Weight
16~58 lb. (60 to 220 g/m
2
) 16~58 lb. (60 to 220 g/m
2
)
Sensing Paper Empty Paper Empty
Tray 1
Capacity
250 sheets @80 g/m
2
250 sheets @80 g/m
2
Media sizes A4, A5, A6, Letter, Legal, Folio,
Oficio, Executive, ISO B5, JIS B5,
Custom
A4, A5, A6, Letter, Legal, Folio,
Oficio, Executive, ISO B5, JIS B5,
Custom
Media Type Plain Paper, Thin, Thick, Recycled,
Bond, Cardstock, Archive
Plain Paper, Thin, Thick, Recycled,
Bond, Cardstock, Archive
Media Weight
16~43 lb. (60 to 163 g/m
2
) 16~43 lb. (60 to 163 g/m
2
)
Sensing Paper Empty Paper Empty
Optional Tray 2
Capacity
550 sheets @80 g/m
2
550 sheets @75 g/m
2
550 sheets @80 g/m
2
550 sheets @75 g/m
2
Media sizes A4, A5, A6, Letter, Legal, Folio,
Oficio, Executive, ISO B5, JIS B5
A4, A5, A6, Letter, Legal, Folio,
Oficio, Executive, ISO B5, JIS B5
Media Type Plain Paper, Thin, Thick, Recycled,
Bond, Cardstock, Archive
Plain Paper, Thin, Thick, Recycled,
Bond, Cardstock, Archive
Media Weight
16~43 lb. (60 to 163 g/m
2
) 16~43 lb. (60 to 163 g/m
2
)
Sensing Paper Empty Paper Empty

Xerox WorkCentre 3345 Specifications

General

Print Technology	Laser
Print Speed	Up to 42 ppm
Print Resolution	Up to 600 x 600 dpi
Automatic Document Feeder	50 sheets
Duplex Printing	Yes
Monthly Duty Cycle	Up to 80, 000 pages
First Page Out Time (Black)	As fast as 6.5 seconds
Processor	600 MHz
Paper Input (Standard)	250 sheets
Paper Output	150 sheets
Scan Resolution (Optical)	Up to 600 x 600 dpi
Fax Speed	33.6 Kbps
Copy Resolution	Up to 600 x 600 dpi
Connectivity	USB, Ethernet, Wi-Fi
Functions	Copy, Print, Scan, Fax, Email
Mobile Printing	Apple AirPrint, Google Cloud Print, Xerox Print Service Plugin for Android, Mopria
Media Sizes Supported	Letter, Legal, A4, A5, B5, A6
Fax Transmission Speed	3 seconds per page
Maximum Paper Size	216 x 356 mm
Copy Speed (Black)	Up to 42 cpm
