Xerox WorkCentre 3345 Service Manual

General Information
Phaser 3330 and WorkCentre 3335/3345 Xerox Internal Use Only
Service Manual
1-18
Understanding the Status LED
The color of the Status LED indicates the machine’s current status.
Status Description
Status LED Off The machine is off-line.
Green Blinking • When the backlight slowly blinks, the machine is receiving or
printing data.
On • The machine is on-line and can be used.
Red Blinking • A minor error has occurred and the machine is waiting for the
error to be cleared. Check the display message. When the
problem is cleared, the machine resumes.
• Small amount of toner is left in the cartridge. The estimated
cartridge life of toner is close. Prepare a new cartridge for
replacement. You may temporarily increase the printing quality
by redistributing the toner.
On • Small amount of toner is left in the cartridge. The estimated
cartridge life of toner is close.
b
Prepare a new cartridge for
replacement. You may temporarily increase the printing quality
by redistributing the toner.
• The cover is opened. Close the cover.
• There is no paper in the tray. Load paper in the tray.
• The machine has stopped due to a major error. Check message
and repair.
• Paper Jam has occurred.
• An Imaging Unit has almost reached its estimated life. Replace
the Imaging Unit.
b. Estimated cartridge life means the expected or estimated Toner Cartridge life, which indicates the average
capacity of print-outs. The number of pages may be affected by operating environment, printing interval,
graphics, media type and media size. Some amount of toner may remain in the cartridge even when red
LED is on and the printer stops printing.
Wireless LED
a
a. Wireless model only.
Blue Blinking/
On
When the printer is connected to a wireless network, the Wireless
LED is illuminated. When the light is blinking, the machine is
transmitting and receiving data from the wireless connection.
Off The printer is disconnected from a wireless network
Power / Wake
up
Blue On The printer is in power saver mode.
Off The printer is in ready mode or the power is off.
ECO Green On Eco mode is on
Off Eco mode is off

Xerox WorkCentre 3345 Specifications

General

Print Technology	Laser
Print Speed	Up to 42 ppm
Print Resolution	Up to 600 x 600 dpi
Automatic Document Feeder	50 sheets
Duplex Printing	Yes
Monthly Duty Cycle	Up to 80, 000 pages
First Page Out Time (Black)	As fast as 6.5 seconds
Processor	600 MHz
Paper Input (Standard)	250 sheets
Paper Output	150 sheets
Scan Resolution (Optical)	Up to 600 x 600 dpi
Fax Speed	33.6 Kbps
Copy Resolution	Up to 600 x 600 dpi
Connectivity	USB, Ethernet, Wi-Fi
Functions	Copy, Print, Scan, Fax, Email
Mobile Printing	Apple AirPrint, Google Cloud Print, Xerox Print Service Plugin for Android, Mopria
Media Sizes Supported	Letter, Legal, A4, A5, B5, A6
Fax Transmission Speed	3 seconds per page
Maximum Paper Size	216 x 356 mm
Copy Speed (Black)	Up to 42 cpm
