Xerox WorkCentre 3345 Service Manual

General Information
Xerox Internal Use Only Phaser 3330 and WorkCentre 3335/3345
Service Manual
1-45
Physical Dimensions and Clearances
Phaser 3330 DN/DNM Dimensions
WorkCentre 3335 Dimensions
WorkCentre 3345 Dimensions
Characteristic Measurement
Height 257 mm (10.1 in.)
Width 366 mm (14.4 in.)
Depth 368 mm (14.5 in.)
Weight (base printer with consumables)
Phaser 3330 12.9 kg (28.4 lbs.)
Characteristic Measurement
Height 449.1 mm (17.2 in.)
Height with 250-Sheet Feeder 595 mm (24.8 in.)
Width 414.6 mm (16.3 in.)
Depth 420.6 mm (16.7 in.)
Weight (base printer with consumables) 17.3 kg (38.2 lbs.)
Characteristic Measurement
Height 482.6 mm (19.0 in.)
Height with 250-Sheet Feeder 628.7 mm (23.4 in.)
Width 467 mm (18.3 in.)
Depth 444.3 mm (17.5 in.)
Weight (base MFP with consumables) 17.3 kg (38.2 lbs.)

Xerox WorkCentre 3345 Specifications

General

Print Technology	Laser
Print Speed	Up to 42 ppm
Print Resolution	Up to 600 x 600 dpi
Automatic Document Feeder	50 sheets
Duplex Printing	Yes
Monthly Duty Cycle	Up to 80, 000 pages
First Page Out Time (Black)	As fast as 6.5 seconds
Processor	600 MHz
Paper Input (Standard)	250 sheets
Paper Output	150 sheets
Scan Resolution (Optical)	Up to 600 x 600 dpi
Fax Speed	33.6 Kbps
Copy Resolution	Up to 600 x 600 dpi
Connectivity	USB, Ethernet, Wi-Fi
Functions	Copy, Print, Scan, Fax, Email
Mobile Printing	Apple AirPrint, Google Cloud Print, Xerox Print Service Plugin for Android, Mopria
Media Sizes Supported	Letter, Legal, A4, A5, B5, A6
Fax Transmission Speed	3 seconds per page
Maximum Paper Size	216 x 356 mm
Copy Speed (Black)	Up to 42 cpm
