Xerox WorkCentre 3345 Service Manual

Troubleshooting
Phaser 3330 and WorkCentre 3335/3345 Xerox Internal Use Only
Service Manual
2-6
Phaser 3330 Service Mode
Enter Service Mode (P3330)
To enter Service Mode, press Menu, and then press the # Key, enter 1934 then press OK.
Service Mode Menu
The Service Mode menu consists of 6 high level menu items: Jobs, Information, Tray Management, Tray Paper
Settings, Tools, and Troubleshooting. The following Menu Map show the menu selections under each high level
menu item.
Phaser 3330 Service Mode Menu Map
LEVEL 1 LEVEL 2 LEVEL 3
Printer
Information
Firmware Version System:
MCB:
IOT:
Network:
IP Core:
Tray 2: Installed/Not Installed
PCL 5e
PCL 6
PS
Tiff
PDF
HFSI Bypass Tray Retard Roll Life Page
T1 Pick-up Roll Life Page
T1 Retard Roll Life Page
Transfer Roll Life Page
Usage Counters Total Print Count
Feed Rolls Count
Optional Tray Feed Roll Count
Transfer Roller Count
Drum Cartridge Count

Xerox WorkCentre 3345 Specifications

General

Print Technology	Laser
Print Speed	Up to 42 ppm
Print Resolution	Up to 600 x 600 dpi
Automatic Document Feeder	50 sheets
Duplex Printing	Yes
Monthly Duty Cycle	Up to 80, 000 pages
First Page Out Time (Black)	As fast as 6.5 seconds
Processor	600 MHz
Paper Input (Standard)	250 sheets
Paper Output	150 sheets
Scan Resolution (Optical)	Up to 600 x 600 dpi
Fax Speed	33.6 Kbps
Copy Resolution	Up to 600 x 600 dpi
Connectivity	USB, Ethernet, Wi-Fi
Functions	Copy, Print, Scan, Fax, Email
Mobile Printing	Apple AirPrint, Google Cloud Print, Xerox Print Service Plugin for Android, Mopria
Media Sizes Supported	Letter, Legal, A4, A5, B5, A6
Fax Transmission Speed	3 seconds per page
Maximum Paper Size	216 x 356 mm
Copy Speed (Black)	Up to 42 cpm
