Xerox WorkCentre 3345 Service Manual

Troubleshooting
Xerox Internal Use Only Phaser 3330 and WorkCentre 3335/3345
Service Manual
2-13
Copier
Diagnostics
(con’t)
dc330 Component Control
(con’t)
09-510 SMPS Fan Run Ready
08-800 Bypass Feed Solenoid (Clutch)
08-810 T1 Pick-Up Solenoid (Clutch)
08-820 T2 Pick-Up Solenoid (Clutch)
08-830 T3 Pick-Up Clutch
08-840 T4 Pick-Up Clutch
08-850 Registration Clutch
08-860 Duplex Feed Clutch
08-870 Duplex Gate Solenoid
08-920 T2 Feed Motor Run
08-930 T3 Feed Motor Run
08-940 T4 Feed Motor Run
01-100 Side Cover Interlock
01-200 Exit Cover Present Sensor
08-720 Out-Bin Full Sensor
07-100 Tray1 Home Position
07-110 T1 Paper Empty Sensor
07-120 T1 size1 sensor
07-130 T1 size2 sensor
07-140 T1 size3 sensor
07-150 T1 Stack Height Sensor
07-160 T1 Paper Low Sensor
07-200 Tray2 Home Position
07-210 T2 Paper Empty Sensor
07-220 T2 size1 sensor
07-230 T2 size2 sensor
07-240 T2 size3 sensor
07-250 T2 Stack Height Sensor
07-260 T2 Paper Low Sensor
LEVEL 1 LEVEL 2 LEVEL 3
