Xerox WorkCentre 3345 Service Manual

Troubleshooting
Phaser 3330 and WorkCentre 3335/3345 Xerox Internal Use Only
Service Manual
2-36
ADF/DADF Jam
Paper jam occurred in the DADF.
Applicable Errors
• 05-100: DADF Jam1
• 05-300: DADF Jam3
• 05-400: DADF Jam4
• 05-700: DADF Jam7
• 05-900: DADF Jam0
Initial Actions
• Open the ADF/DADF Cover and remove all originals from the document feeder.
• Turn the machine off and then on, if the error persists use the following procedure.
Troubleshooting Reference Table
Applicable Parts Wiring and Plug/Jack Map Reference
• DADF Pick Up Unit (PL 8.1A .16, Parts List
8.1A WorkCentre 3345 DADF)
• ADF Pick Up Assembly (PL 7.1.9 and PL
.7.1.10, Parts List 7.1 WorkCentre 3335
SCANNER and ADF)
•ADF Paper Path Assembly, (ADF Paper
Path Assembly (WorkCentre 3335))
• DADF Feed Roller (PL 8.2.14, Parts List
8.2 WorkCentre 3345 Lower DADF)
• DADF Rubber Unit (PL 8.2.14, Parts List
8.2 WorkCentre 3345 Lower DADF)
• DADF Lifting Solenoid (PL 8.18, Parts List
8.1 WorkCentre 3345 SCANNER and
DADF).
• DADF Feed Sensor (PL 8.2.24, Parts List
8.2 WorkCentre 3345 Lower DADF)
• DADF Registration Sensor (PL 8.2.13,
Parts List 8.2 WorkCentre 3345 Lower
DADF)
• DADF Drive (PL 8.5.8, Parts List 8.5
WorkCentre 3345 Drive DADF)
• ADF Motor (PL 7.1A.16, Parts List 7.1A
WorkCentre 3335 ADF)
• DADF Assembly (PL 8.1A.1, Parts List
8.1A WorkCentre 3345 DADF)
• ADF Assembly (PL 7.1A.1, Parts List 7.1A
WorkCentre 3335 ADF)
• Phaser 3330 Main PWB Connector Designators
• Phaser 3330 Control Panel PWB
• Wiring Diagrams for P3330/WC3335/WC3345
• WorkCentre 3335/3345 Main PWB Connector Designators
•DADF PWB
•SMPS PWB

Xerox WorkCentre 3345 Specifications

General

Print Technology	Laser
Print Speed	Up to 42 ppm
Print Resolution	Up to 600 x 600 dpi
Automatic Document Feeder	50 sheets
Duplex Printing	Yes
Monthly Duty Cycle	Up to 80, 000 pages
First Page Out Time (Black)	As fast as 6.5 seconds
Processor	600 MHz
Paper Input (Standard)	250 sheets
Paper Output	150 sheets
Scan Resolution (Optical)	Up to 600 x 600 dpi
Fax Speed	33.6 Kbps
Copy Resolution	Up to 600 x 600 dpi
Connectivity	USB, Ethernet, Wi-Fi
Functions	Copy, Print, Scan, Fax, Email
Mobile Printing	Apple AirPrint, Google Cloud Print, Xerox Print Service Plugin for Android, Mopria
Media Sizes Supported	Letter, Legal, A4, A5, B5, A6
Fax Transmission Speed	3 seconds per page
Maximum Paper Size	216 x 356 mm
Copy Speed (Black)	Up to 42 cpm
