Xerox WorkCentre 6515 User Manual

Troubleshooting
To prevent paper jams:
• Do not load original documents above the MAX fill line.
• Adjust the paper guides so that they fit against the original documents.
• Use only supported paper. For details, refer to Single-Pass Duplex Automatic Document Feeder
Guidelines on page 121.
Clearing Paper Jams from the Bypass Tray
To resolve the error displayed on the control panel, you must clear all paper from the paper path.
1. Remove any paper from the Bypass Tray.
2. Grasp both sides of the Bypass Tray, then pull it straight out of the printer.
3. Remove Tray 1 from the printer.
Xerox
®
WorkCentre
®
6515 Color Multifunction Printer 201
User Guide

Xerox WorkCentre 6515 Specifications

General

Print Technology	Laser
Print Resolution	Up to 1200 x 2400 dpi
Scan Resolution	Up to 600 x 600 dpi
Copy Resolution	Up to 600 x 600 dpi
Fax Resolution	Up to 400 x 400 dpi
Monthly Duty Cycle	Up to 50, 000 pages
Automatic Duplexing	Yes
Functions	Print, Copy, Scan, Fax
Memory	2 GB
Fax Speed	33.6 Kbps
Paper Output	150 sheets
Fax Transmission Speed	3 seconds per page
Standard Paper Capacity	300 sheets
Connectivity	USB, Ethernet
Mobile Printing	Apple AirPrint, Google Cloud Print, Mopria, Xerox Print Service Plug-in for Android
Maximum Paper Size	8.5 x 14 inches
Dimensions	420 x 506 x 500 mm
Print Speed	Up to 30 ppm
Paper Input	Bypass Tray: 50 sheets; Tray 1: 250 sheets
