December 2006
6-59
WorkCentre M20, 4118, FaxCentre 2218 Family
GP 20
General Procedures and Information
CBF signal - CCD FFC CCD - Charge coupled device
FFC - Flexible flat cable
PL 14.11 Item 17
Cover - M - CCD cable M - Mold
CCD - Charge coupled device
PL 14.11 Item 15
Cover - M - front M - Mold PL 4.25 Item 8
Cover - M - OPE M - Mold
OPE - Operation panel (control panel)
PL 2.10 Item 14
PL 2.15 Item 2
Cover - scan lower (UMAX) UMAX - Suppliers name for CCD
module
PL 14.11 Item 22
ELA Unit - OPC drum set OPC - Organic photo-conductive PL 9.10 Item 1
ELA HOU - MP assembly MP - Multi purpose (bypass) tray PL 8.20 Item 1
ELA HOU - scanner assembly ELA - Electrical assembly
HOU - Housing
PL 14.10 Item 1
ELA M/M - AUD speaker ELA M/M - Electrical assembly M/M
AUD - Audio
PL 4.10 Item 14
Gear - exit/U Exit/U - Exit/upper PL 4.20 Item 6
Gear - exit/U, ID U - Upper
ID - Idler
PL 4.17 Item 4
Gear - MP/DUP DRV MP - Multi purpose (bypass) tray
DUP DRV - Duplex driver
PL 8.10 Item 5
Gear - RDCN feed inner RDCN - Reduction PL 4.20 Item 15
Ground - P_scan roller Ground - P - Ground press PL 5.11 Item 2
Holder catch CST MC2 MC2 - Development code name for
machine
PL 4.10 Item 6
ICT - insert shaft ICT - Iron cutting PL 14.11 Item 8
ICT - shaft - exit lower ID ID - Idler PL 10.10 Item 12
IPR
- BRK scan BD IPR - Iron press
BRK - Bracket
BD - Board
PL 14.11 Item 11
IPR - BRKT G DUP IPR - Iron press
BRKT - Bracket
G - Ground
DUP - Duplex
PL 8.10 Item 11
IPR - ground plate A (OPC) OPC - Organic photo conductive PL 4.10 Item 8
IPR - ground plate SCF SCF - Second cassette feeder (tray2) PL 4.10 Item 21
IPR - guard C/O S/W C/O - Cover open
S/W - Switch
PL 5.11 Item 13
IPR - holder glass IPR - Iron press PL 14.10 Item 10
IPR - shield SMPS upper IPR - Iron press PL 1.12 Item 1
PL 1.15 Item 1
PL 1.20 Item 1
IPR - terminal FU FU - Fuser PL 4.17 Item 8
IPR - washer spring CU CU - Curve PL 5.10 Item 22
Table 1 Acronyms
Acronym Description PL Ref.
IPR-P_pinch (scan) IPR-P - Iron press PL 5.14 Item 6
Key - M - copy M - Mold PL 2.11 Item 4
PL 2.15 Item 4
PL 2.18 Item 6
MCT - glass DADF MCT - Machinery cutting PL 14.10 Item 4
MCT - glass scanner (legal) MCT - Machinery cutting PL 14.10 Item 12
MEA unit - cover PA exit assembly MEA - Mechanical assembly
PA - Paper
PL 4.25 Item 1
MEA unit - TX stacker TX - Transmit PL 5.10 Item 18
MEA unit guide CST PA assembly CST - Cassette (paper tray)
PA - paper
PL 4.25 Item 10
MEC - cassette assembly (letter) MEC - Mechanical combined unit PL 7.10 Item 1
Motor step - MCK2 (main) MCK2 - Development code name for
machine
PL 4.20 Item 2
MPR - name/plate XRX MPR - Machinery Press
XRX - Xerox
PL 4.25 Item 7
PBA LIU PBA - Printed circuit board assembly
LIU - Line Interface unit for FAX
PL 1.10 Item 7
PL 1.15 Item 11
PL 1.20 Item 11
PBA main PBA - Printed circuit board assembly PL 1.10 Item 9
PL 1.15 Item 9
PL 1.20 Item 9
PBA SUB - D_SUB PBA SUB - D_SUB - Sub printed cir-
cuit board assembly for the D-SUB
type electrical connector.
PL 14.11 Item 5
PBA SUB - feed + P. EMP SEN PBA SUB - feed - Sub printed circuit
board assembly for the feeder and
paper empty sensor
P. EMP SEN - Paper empty sensor
PL 8.25 Item 12
PBA SUB - MP SEN PBA SUB - MP SEN - Sub printed cir-
cuit board assembly for the MP-SEN
(Multi purpose (bypass) tray sensor)
PL 8.20 Item 24
PBA SUB - PTL PBA SUB - PTL - Sub printed circuit
board assembly for the PTL (pre
transfer lamp)
PL 8.25 Item 6
PBA SUB - REGI PBA SUB - REGI - Sub printed circuit
board assembly for the registration
PL 5.10 Item 9
PMO - bushing finger, FF - Front PL 7.10 Item 19
PMO - bushing P/U MP P/U - Pickup
MP
- Multi purpose (bypass) tray
PL 8.13 Item 2
PMO - BUSHING P/U,MP P/U - Pickup
MP - Multi purpose (bypass) tray
PL 8.11 Item 4
PMO - bushing TX (B4) TX - Transmit PL 8.10 Item 8
PMO - cam jam remove PMO - Processing mold PL 4.25 Item 22
Table 1 Acronyms
Acronym Description PL Ref.
