XITRON XT2640 - Measurement Configuration Edit Commands

XT2640OperatingManual 13July2016 Page145of187

COMMAND
KEYWORD
FIELD(s)
FIELD
FORMAT
FIELDDATA
RANGE
DESCRIPTION
5:AEN505645.3.2ameasurementisinprogressandhasbeen
extendedbeyondthespecifiedminimumtimeperiod(datais
available).
6:AEN505645.3.2dmeasurementisinprogress(dataisavailable).

24.4.9 MEASUREMENT CONFIGURATIONEDIT COMMANDS
TheMeasurementConfigurationEditcommandsshownbelowhavebeensplitintoseparatesectionsforclarity;allofthecommands
describedinthesesectionsarecontrolledbytheEDITCONFIGandSAVECONFIGcommands.
WhileperforminganinternalDCzeroyoushouldnotsendanyofthesecommandstotheXT2640.
Thesecommandsarecheckedonlyforsyntaxandcompatibilitywiththeinstalledhardware(ifapplicable)wheneachcommandis
receivedandarenotexecutedandtheconsistencyofsettingcombinationsarenotcheckeduntiltheSAVECONFIGcommandisused.
Inthismanneryoumayconfiguremeasurementsusingthesecommandsinanyorderwithouttheneedtoconsiderintermediate
potentiallyincompatiblesettingcombinations.Forthisreason,theCH1toCH4variantsoftheVDEFfieldformatarenotallowedfor
thesecommands.
Ifyouareunsureifthereareanypendingcommandsfromthesesections(e.g.fromapriorsessionwheretheSAVECONFIG
commandwasnotused)thenyoumayusetheEDITCONFIGcommandtoensurethattherearenone(the*RSTor*CLScommand
alsoaccomplishthisandaretherecommendedmethodbutalsoperformotherfunctions).
Atypicalcommandflowis‐
SendtheEDITCONFIGcommand(onlytoensuretherearenopreviouslyunsavedmeasurementconfigurationchanges)
Sendtherequiredmeasurementconfigurationcommands(inanyorder)
SendtheSAVECONFIGcommand(toexecutethepriormeasurementconfigurationcommands)
Theabovecommandflowcanbesentinanynumberofsetsofcommands,includingallinthesamesetofcommands.
COMMAND
KEYWORD
FIELD(s)
FIELD
FORMAT
FIELD
DATA
RANGE
DESCRIPTION
EDITCONFIG ‐ ‐ ‐
Setstheconfigurationtobeedited bytheinterface tothatpresentlybeingusedinthe
XT2640.
SAVECONFIG ‐ ‐ ‐
SetsthepresentlyusedconfigurationwithintheXT2640toincludeallchangesmade
viatheinterfacesincethepriorEDITCONFIGorSAVECONFIGcommand.Whenthis
commandisexecutedallmeasurementsinprogressmaybeabandonedandrestarted
withthechangedconfiguration(dependingonthechangesmade)
24.4.9.1 MEASUREMENTMODECONFIGURATIONCOMMAND
COMMAND
KEYWORD
FIELD(s)
FIELD
FORMAT
FIELDDATA
RANGE
DESCRIPTION
MODE m NR1 0to7
SetstheoveralloperatingmodefortheXT2640‐
m=0:SingleVPAmode
m=1:Multi‐VPAmode(onlyvalidifmorethanonechannelfitted)
m=2:Sync‐VPAmode(onlyvalidifmorethanonechannelfitted)
m=3:EN61000‐3‐2mode(onlyvalidifoptionsH500andENare
installed).
m=5:EN61000‐3‐12mode(onlyvalidifoptionsH500andENare
installed).
fittedandoptionENisinstalled)
m=7:SPECTRUMmode(onlyvalidifoptionH500isinstalled)
24.4.9.2 CHANNELCONFIGURATIONCOMMANDS
COMMAND
KEYWORD
FIELD(s)
FIELD
FORMAT
FIELDDATARANGE DESCRIPTION
ARANGE
c CDEF ‐ Setsthecurrentinputrangeforchannel
c
–
r=0:SelectstheHIrange
r=1:selectstheLOrange
r=2:selectsforauto‐range(onlyvalidforaDcurrentinput
channel)
r NR1
Hinput:0only
Dinput:0to2
Xinput:0to1
ASCALE
c CDEF ‐ Setsthe currentscalingandoffsetforchannelc
Ifs=zerothenturnsoffscalingandoffset(oisignored),
otherwiseturnsonscalingandoffsetusingsando
respectively
Fieldoisoptional,zeroisusedifnotpresent
s NR3 0.0,or+1e‐6to+1e6
o NR3
Withinthemeasurablerangeof
thechannelcurrentoption
VSCALE
c CDEF ‐ Setsvoltagescalingforchannelc
Ifs=zerothenturnsoffscaling
Otherwiseturnsonvoltagescalingusings
s NR3 0.0,or+1e‐3to+1e6
24.4.9.3 VPACONFIGURATIONCOMMANDS
COMMAND
KEYWORD
FIELD(s)
FIELD
FORMAT
FIELDDATA
RANGE
DESCRIPTION
ADJUST v VDEF ‐
