XITRON XT2640 - Ø 3 W or 3 Ø 3 W (2 Ch ) Wiring Using Internal Current Measurement

XT2640OperatingManual 13July2016 Page23of187

9.4 2Ø3WOR3Ø3W(2CH)WIRINGUSINGINTERNALCURRENTMEASUREMENT

CAUTION:
 FORUSEWITHSH,SD,AH,AD,LH,LD,WHORWDCHANNELSONLY
 DONOTCONNECTWIRINGWHILEVOLTAGEPRESENT.
 ENSUREWIRINGISCORRECTBEFOREAPPLYINGVOLTAGE.
 DONOTPASSLOADCURRENT>2ArmsWITHTHEXT2640TURNEDOFF.
WIRING:
 Thickerconnectionsarecurrentcarrying.Ensurewireusedisratedforthemaximumvoltageandcurrenttobe
encountered.
 Thinnerconnectionsarenotcurrentcarrying.Ensurewireusedisratedforthemaximumvoltagetobeencountered.

Phasesareshownfordescriptivepurposes,theXT2640placesnorelianceontheactualphasinghoweverusingthose
shownensuresthattheXT2640displaymatchestheactualphasingifthechannelshaveincreasingchannelnumbersfrom
lefttorightinthediagramabove.
 Thewiringconnectionsshownaboveensurethebestoverallsystemaccuracyinmostcircumstances,measuringthe
voltageatthesourceandtheloadcurrent.Forapplicationsrequiringaccuratemeasurementsofthepowertotheloadand
usinglowvoltages(<50V)andhighcurrents(>1A)changetheREDV+terminalconnectionstothatoftherespectiveBLUE
A‐terminalinsteadoftheYELLOWA+terminalshownabove,thisensuresthatthevoltagedropacrosstheAterminalsdoes
notaffecttheVmeasurement,attheexpenseofthecurrentandpowermeasurementsincludingthecurrentandpower
drawnbytheVinput(whichmaybeadjustedforbyusingtheADJUSTsettingintheMEASCONFIGscreen).
XT2640CONFIGURATION:
 IntheXT2640MEASCONFIGmenuyoushouldsetSCALEforthechannelstoOFF.
 ForeitherconnectionmethodyoumayusetheADJUSTsettingintheMEASCONFIGmenutosettheXT2640toadjustthe
signalsfortheconnectionmethodandwhethersourceorloadresultsarerequired.


N or øC
From
SOURCE
øA
To
LOAD
øB
To
LOAD
N or øC
To
LOAD
A
V
øA
From
SOURCE

XT2640
C
H
A
V

XT2640
CH
øB
From
SOURCE
