XITRON XT2640 - Ø Wiring Using External Current Measurement

XT2640OperatingManual 13July2016 Page21of187

9.2 1ØWIRINGUSINGEXTERNALCURRENTMEASUREMENT

CAUTION:
 FORANA:ATYPECT:USEWITHSH,SD,AH,AD,LH,LD,WHORWDCHANNELSONLY
 FORANA:VTYPECTORASHUNT:USEWITHSX,AX,LXORWXCHANNELSONLY
 DONOTCONNECTWIRINGWHILEVOLTAGEPRESENT.
 ENSURE
WIRINGISCORRECTBEFOREAPPLYINGVOLTAGE.
WIRING:
 Thickerconnectionsarecurrentcarrying.Ensurewireusedisratedforthemaximumvoltageandcurrenttobe
encountered.
 Thinnerconnectionsarenotcurrentcarrying.Ensurewireusedisratedforthemaximumvoltagetobeencountered.
 ManyCTdevicesareisolating,inthosecasesyoushouldgroundtheA‐(BLUE)terminalofthechanneliftheCTdoesnot
groundit.
XT2640CONFIGURATION:
 IntheXT2640MEASCONFIGmenuyoushouldappropriatelysetSCALEforthechanneltosuittheCTorshuntbeingused
(bothascalefactorandanoffsetareavailable).


A
V
L or
HI
N or
LO
L or
HI
N or
LO
From
SOURCE
To
LOAD

XT2640
CH
CT
+ -
