XT2640OperatingManual 13July2016 Page186of187

e.
Afterthelaststephasbeencompletedforthischannel(thereareupto12stepsforeachchannel)presstheSAVE
ADJUSTMENTSbuttontosavetheadjustmentstothechannelandreturntoselectingthenextchanneltoadjust.
f.
NOTE:pressingtheABORTADJUSTMENTSbuttonatanytimeduringtheadjustmentofachannelwilldiscardany
adjustmentsmadetothatchanneluntiltheSAVEADJUSTMENTSbuttonispressed.
31.2.3 FINISHINGTHEPROCEDURE
Whenalladjustmentshavebeenperformedonallchannelsrequiringadjustment,theusermaypresstheDISCONNECTbuttonto
disconnecttheapplicationfromtheXT2640.Theadjustmentsweresavedwheneachchanneladjustmentwascompleted.
WARNING:DonotremovepowerfromtheXT2640duringoruntilatleast10secondsaftercompletingadjustments.
 
