XT2640OperatingManual 13July2016 Page60of187

2.
Displaythescreentoberecorded.
3.
PresstheDRIVEINFOareaofthescreen,thescreenshowsthefileexport/importscreen.
4.
PresstheSCREENIMAGEbutton.Thescreenchangestoallowingyoutoenterafilename.
5.
Enterthedesiredfilename(theextensionisautomaticallyprovided).
6.
Ifthefilealreadyexiststhenyouarepromptedtorespondifyouwishtooverwriteitornot.
7.
Thefileisthenwritten.
12.9.8 HISTORICAL DATA AVAILABILITY
Notallmeasureddataareavailable,theavailabledataareshowninthelistprovidedbelowwhichhasbeenshortenedbytheuseof
thefollowing–
CHn AnyofCH1,CH2,CH3orCH4
An AnyofVPA1,VPA2orVPA3
pX AnyoføA,øB,øCorøD
Hn AnyofH1…3

FREQ:CHn
FREQ:An
VOLTS:CHn:DC
VOLTS:CHn:AC
VOLTS:CHn:ACDC
VOLTS:CHn
VOLTS:CHn:CF
VOLTS:CHn:PK
VOLTS:CHn:HIPK
VOLTS:CHn:LOPK
VOLTS:CHn:Hn
VOLTS:CHn:P1
VOLTS:CHn:THDf
VOLTS:CHn:THDsig
VOLTS:CHn:VALLEY
VOLTS:CHn:PK‐VLY
VOLTS:An:pX:DC
VOLTS:An:pX:AC
VOLTS:An:pX:ACDC
VOLTS:An:pX
VOLTS:An:pX:CF
VOLTS:An:pX:PK
VOLTS:An:pX:HIPK
VOLTS:An:pX:LOPK
VOLTS:An:pX:Hn
VOLTS:An:pX:P1
VOLTS:An:pX:THDf
VOLTS:An:pX:THDsig
VOLTS:An:øAC:AC
VOLTS:An:øAC:ACDC
VOLTS:An:øAC
VOLTS:An:øAC:CF
VOLTS:An:øAC:PK
VOLTS:An:øAC:HIPK
VOLTS:An:øAC:LOPK
VOLTS:An:øAC:Hn
VOLTS:An:øAC:P1
VOLTS:An:øAC:THDf
VOLTS:An:øAC:THDsig
VOLTS:An:øBC:AC
VOLTS:An:øBC:ACDC
VOLTS:An:øBC
VOLTS:An:øBC:CF
VOLTS:An:øBC:PK
VOLTS:An:øBC:HIPK
VOLTS:An:øBC:LOPK
VOLTS:An:øBC:Hn
VOLTS:An:øBC:P1
VOLTS:An:øBC:THDf
VOLTS:An:øBC:THDsig
VOLTS:An:øAB:AC
VOLTS:An:øAB:ACDC
VOLTS:An:øAB
VOLTS:An:øAB:CF
VOLTS:An:øAB:PK
VOLTS:An:øAB:Hn
VOLTS:An:øAB:P1
VOLTS:An:øAB:THDf
VOLTS:An:øAB:THDsig
VOLTS:An
VOLTS:An:PK
VOLTS:An:H1
AMPS:CHn:DC
AMPS:CHn:AC
AMPS:CHn:ACDC
AMPS:CHn
AMPS:CHn:CF
AMPS:CHn:PK
AMPS:CHn:HIPK
AMPS:CHn:LOPK
AMPS:CHn:Hn
AMPS:CHn:P1
AMPS:CHn:THDf
AMPS:CHn:THDsig
AMPS:CHn:VALLEY
AMPS:CHn:PK‐VLY
AMPS:An:pX:DC
AMPS:An:pX:AC
AMPS:An:pX:ACDC
AMPS:An:pX
AMPS:An:pX:CF
AMPS:An:pX:PK
AMPS:An:pX:HIPK
AMPS:An:pX:LOPK
AMPS:An:pX:Hn
AMPS:An:pX:P1
AMPS:An:pX:THDf
AMPS:An:pX:THDsig
AMPS:An:N:DC
AMPS:An:N:AC
AMPS:An:N:ACDC
AMPS:An:N
AMPS:An:N:CF
AMPS:An:N:PK
AMPS:An:N:H1
AMPS:An
AMPS:An:PK
AMPS:An:H1
WATTS:CHn:DC
WATTS:CHn:AC
WATTS:CHn:ACDC
WATTS:CHn
WATTS:CHn:H1
WATTS:An:pX:DC
WATTS:An:pX:AC
WATTS:An:pX:ACDC
WATTS:An:pX
WATTS:An:pX:H1
WATTS:An:øAC:DC
WATTS:An:øAC:AC
WATTS:An:øAC:ACDC
WATTS:An:øAC
WATTS:An:øAC:H1
WATTS:An:øBC:DC
WATTS:An:øBC:AC
WATTS:An:øBC:ACDC
WATTS:An:øBC
WATTS:An:øBC:H1
WATTS:An:DC
WATTS:An:AC
WATTS:An:ACDC
WATTS:An
WATTS:An:H1
WATTS:IN
WATTS:MIDDLE
WATTS:OUT
LOSS:IN‐MID
LOSS:IN‐OUT
LOSS:MID‐OUT
EFFICIENCY:IN‐MID
EFFICIENCY:IN‐OUT
EFFICIENCY:MID‐OUT
VAR:CHn:AC
VAR:CHn:ACDC
VAR:CHn
VAR:CHn:H1
VAR:An:pX:AC
VAR:An:pX:ACDC
VAR:An:pX
VAR:An:pX:H1
VAR:An:øAC:AC
VAR:An:øAC:ACDC
VAR:An:øAC
VAR:An:øAC:H1
VAR:An:øBC:AC
VAR:An:øBC:ACDC
VAR:An:øBC
VAR:An:øBC:H1
VAR:An:AC
VAR:An:ACDC
VAR:An
VAR:An:H1
VA:CHn:DC
VA:CHn:AC
VA:CHn:ACDC
VA:CHn
VA:CHn:H1
VA:An:pX:DC
VA:An:pX:AC
VA:An:pX:ACDC
VA:An:pX
VA:An:pX:H1
VA:An:øAC:DC
VA:An:øAC:AC
VA:An:øAC:ACDC
VA:An:øAC
VA:An:øAC:H1
VA:An:øBC:DC
VA:An:øBC:AC
VA:An:øBC:ACDC
VA:An:øBC
VA:An:øBC:H1
VA:An:DC
VA:An:AC
VA:An:ACDC
VA:An
VA:An:H1
PF:CHn:AC
PF:CHn:ACDC
PF:CHn
PF:CHn:H1
PF:An:pX:AC
PF:An:pX:ACDC
PF:An:pX
PF:An:pX:H1
PF:An:øAC:AC
PF:An:øAC:ACDC
PF:An:øAC
PF:An:øAC:H1
PF:An:øBC:AC
PF:An:øBC:ACDC
PF:An:øBC
PF:An:øBC:H1
PF:An:AC
PF:An:ACDC
PF:An
PF:An:H1
LOADZ:CHn:DC
LOADZ:CHn:AC
LOADZ:CHn:ACDC
LOADZ:CHn
LOADZ:CHn:H1
MOTOR:WATTS
MOTOR:SPEED
MOTOR:TORQUE
MOTOR:SLIP
