8.4 TYPICALDUAL VPAAPPLICATIONS
ExamplesofdualVPAapplicationsasshowninthediagrambelowinclude–
ACtoDCPowerSupplies(singleormultipleoutputs)
DCtoDCPowerSupplies(singleormultipleoutputs)
DCorfixedfrequencyACsuppliedvariableorfixedspeedmotordrives
PowerTransformers(singleormulti‐phase)
LightingBallasts(mosttypes)
StandbyorBackupPowerSupplies(ACorDC)
PhotovoltaicPowerGenerators(DCin;DCorACout)
TherearealsootherdualVPAconfigurationswhicharenotshownhere.Asexamples–
Iftheneutralcurrentistobeactuallymeasuredratherthancomputedfromtheotherphasesfora2ø3wor3ø4wsupplyor
loadthenthatisaccomplishedbyusingasecondVPAforjusttheneutralcurrentmeasuringchannelandsettingthatVPA
tobefullysynchronouswiththemainVPA.
IfaloadhasbothACandDCsupplyinputs(orviceversa),ortwodifferentfrequencyACsupplies,theneachsupplycanbe
measuredinseparateVPAsandanefficiencygroupusedtoproducethetotalinput(oroutput)powerfrombothVPAs.


 EachVPAisindependentlyconfiguredandhasthesamecapabilitiesaspreviouslydescribedforsingleVPAapplications
(exceptonlyasingleoscilloscopeinoneVPAisallowed).
 EachVPAcanbeconfiguredasNx1ø,2ø3w,3ø3w(2ch),3ø3w(3ch)or3ø4wlimitedbythetotalnumberofchannels
installed.
 Overallefficiencyandpowerlosscanbemeasured.
 ThetwoVPAsmaybeconfiguredaseither–
Totallyindependentandhavingtotallydifferentfrequencycontentsignalstoeachother.
Or,havetotallydifferentfrequencycontentsignalsbutmakemeasurementsovertimeswhicharesynchronized
toeachother.
Or,havethesamefrequencycontentsignalsandmakemeasurementsoverexactlythesameperiodsoftime(the
oscilloscopecapturesthesignalsinbothVPAsinthiscase).


XT2640
POWER
SOURCE
POWER
CONVERSION
VPA
1 to 4
channels
LOAD
VPA
1 to 4
channels
