XITRON XT2640 - Ø Wiring Using 280 X Iec Adaptor Cord

XT2640OperatingManual 13July2016 Page22of187

9.3 1ØWIRINGUSING280X IECADAPTORCORDADAPTOR
ThisistherecommendedwiringmethodwhenperformingEN50564:2011compliantmeasurementswithasinglephasesupplyand
load.

CAUTION:
 FORUSEWITHSH,SD,AH,AD,LH,LD,WHORWDCHANNELSONLY
 DONOTCONNECTWIRINGWHILEVOLTAGEPRESENT.
 ENSURETHATEACHXT2640TERMINALCOLORMATCHESTHEWIRECONNECTORCOLORBEFOREAPPLYINGTHE
SOURCEVOLTAGE.
 DONOTPASSLOADCURRENT>2ArmsWITH
THEXT2640TURNEDOFF.
XT2640CONFIGURATION:
 IntheXT2640MEASCONFIGmenuyoushouldsetSCALEforthechanneltoOFF.
 IntheXT2640MEASCONFIGmenuyoushouldsetADJUSTfortheVPAtoNONE,SRCE(V@SRCE)orLOAD(V@SRCE)
accordingtoyourspecificrequirement.


From
SOURCE
A
V
XT2640
CH



To LOAD
