XT2640OperatingManual 13July2016 Page151of187

COMMAND
KEYWORD
FIELD(s)
FIELD
FORMAT
FIELD
DATA
RANGE
DESCRIPTION
SPD? ‐ ‐ ‐
RespondswiththeNR1indicatingtheconfiguredSPDinpu
t
‐
0:Nospeedmeasurement
1:SpeedmeasuredusingananaloginputontheSPDconnector
2:SpeedmeasuredusingadigitalinputontheSPDconnector
3:SpeedmeasuredusingadigitalinputontheSPDconnectorwithdirection
indicatedbythedigitalinputontheDIRconnector
4:SpeedderivedfromtheelectricaldrivefrequencymeasuredinVPA1(onlyvalid
ifVPA1configuredforuse)
5:SpeedderivedfromtheelectricaldrivefrequencymeasuredinVPA2(onlyvalid
ifVPA2configuredforuse)
6:SpeedderivedfromtheelectricaldrivefrequencymeasuredinVPA3(onlyvalid
ifVPA3configuredforuse)
SPDOFFSET? ‐ ‐ ‐ RespondswiththeNR3settingforthespeedmeasurementoffset
SPDRISING? ‐ ‐ ‐
RespondswithNR1indicatingiftherisingedge(1)orthefallingedgeoftheSPD
digitalinputisbeingdetected
SPDSCALE? ‐ ‐ ‐ RespondswiththeNR3settingforthespeedmeasurementscaling
STBY? v VDEF ‐
RespondswiththestandbypowermeasurementsettingsforVPAv–
IftheconfiguredmethodisEN505645.3.2a:
1
st
fieldisaSTRINGofvalueA
2
nd
fieldisaNR1withthedaysminimummeasurementtimesetting
3
rd
fieldisaNR1withthedaysminimummeasurementtimesetting
4
th
fieldisaNR1withthedaysminimummeasurementtimesetting
5
th
fieldisaNR1withthedaysminimummeasurementtimesetting
IftheconfiguredmethodisEN505645.3.2d:
1
st
fieldisaSTRINGofvalueD
2
nd
fieldisaNR3withthestartingpowerdetectionlevelsetting
3
rd
fieldisaNR3withtheendingpowerdetectionlevelsetting
TIMEBASE? ‐ ‐ ‐
RespondswiththeNR1scopedatacapturetimebasesettingas5µs(0),10µs(1),
20µs(2),50µs(3),100µs(4),200µs(5),500µs(6),1ms(7),2ms(8),5ms(9),
10ms(10),20ms(11),50ms(12),100ms(13),200ms(14),500ms(15),1s(16),
2s(17),5s(18),10s(19)or20s(20)
TRIGGER? ‐ ‐ ‐
Respondswiththescopedatacapturetriggerssettingsasthefollowingfourfields
–
1
st
field(NR1)isthetriggerinputselection‐
0:TriggerusingCH1Vinputsignal
1:TriggerusingCH1Ainputsignal
2:TriggerusingCH2Vinputsignal
3:TriggerusingCH2Ainputsignal
4:TriggerusingCH3Vinputsignal
5:TriggerusingCH3Ainputsignal
6:TriggerusingCH4Vinputsignal
7:TriggerusingCH4Ainputsignal
2
nd
field(NR1)isthetriggermethodselection–
0:DCrisingedge
1:DCfallingedge
2:Rectifiedsignal(risingedge)
3:HighFrequency
3
rd
field(NR1)isthetriggerpositionselection‐
0:triggerisat0%ofthecapturedtimespan
1:triggerisat25%ofthecapturedtimespan
2:triggerisat50%ofthecapturedtimespan
3:triggerisat75%ofthecapturedtimespan
4
th
field(NR3)istheconfiguredtriggerlevelinVorAunitsasapplicable
TRQ? ‐ ‐ ‐
RespondswiththeNR1indicatingtheconfiguredTRQinput‐
0:Notorquemeasurement
1:TorquemeasuredusingananaloginputontheTRQconnector
2:TorquemeasuredusingadigitalinputontheTRQconnector
TRQOFFSET? ‐ ‐ ‐ RespondswiththeNR3settingforthetorquemeasurementoffset
TRQSCALE? ‐ ‐ ‐ RespondswiththeNR3settingforthetorquemeasurementscaling
VSCALE? c CDEF ‐
RespondswiththeNR3voltagescalingsetting(0.0ifnotconfiguredforscaling)
forchannelc
VPA? c CDEF ‐
RespondswiththeNR1indicatingwhichVPAchannelcisconfiguredin(1through
3)orifnotconfiguredornotinstalled(0)
WIRING? v VDEF ‐
RespondswiththeNR1wiringmethodsettingforVPAv –
0:Nx1ømethod.
1:2ø3wmethod.
2:3ø3w(2channel)method.
3:3ø3w(3channel)method.
4:3ø4wmethod
24.4.11 CONFIGURATIONSAVEANDLOADCOMMANDS
ThesecommandsallowtheusertotemporarilysaveandreloadthecompleteconfigurationoftheXT2640(thesavedconfigurationisvolatile,i.e.itis
notretainedafterapowercycle).
