XITRON XT2640 - Page 150

XT2640OperatingManual 13July2016 Page150of187

COMMAND
KEYWORD
FIELD(s)
FIELD
FORMAT
FIELD
DATA
RANGE
DESCRIPTION
LOGDELAY? ‐ ‐ ‐
RespondswiththepresentdelaytimefordataloggingasfourNR1fieldsindicating
thedays,hours,minutesandsecondsrespectively.
LOGFILE? ‐ ‐ ‐
Respondswiththepresentfilesettingsfordatalogging–
1
st
field(NR1)indicatesifthefileisinbinary(1)orASCII(0)formatorsavedto
internalmemory(2)
2
nd
field(NR1)indicatesifaheaderrecordwillbeincluded(1)ornot(0)
3
rd
field(NR1)indicatesifanexistingfilewillbeappendto(1)oroverwritten(0)
4
th
field(STRING)isthefilename(includingextension)
LOGINTERVAL? ‐ ‐ ‐
RespondswiththepresentintervalfordataloggingasfourNR1fieldsindicating
thehours,minutes,secondsand0.01secondsrespectively.
LOGRUN? ‐ ‐ ‐
RespondswiththepresentruntimefordataloggingasfourNR1fieldsindicating
thedays,hours,minutesandsecondsrespectively(manuallycontrolledifallfields
are0)
MODE? ‐ ‐ ‐
RespondswithaNR1showing the presen
t
overalloperatingmodefortheXT2640.
0:SingleVPAmode
1:Multi‐VPAmode
2:Sync‐VPAmode
3:EN61000‐3‐2mode
5:EN61000‐3‐12mode
7:SPECTRUMmode
MTRDIGITS? ‐ ‐ ‐ RespondswithNR1numberofdisplayeddigitsformotormeasurementresults.
MTREFFGROUP? ‐ ‐ ‐
RespondswiththeNR1efficiencygroup settingformotorpower–
0:None
1:IN
2:MIDDLE
3:OUT
MTRPERIOD? ‐ ‐ ‐
RespondswiththeNr1measurementperiodformotormeasurements‐
0:10msmeasurementperiod
1:30msmeasurementperiod
2:100msmeasurementperiod
3:300msmeasurementperiod
4:1smeasurementperiod
5:3smeasurementperiod
6:10smeasurementperiod
7:30smeasurementperiod
8:100smeasurementperiod
9:MeasurementperiodsynchronouswithVPA1
10:MeasurementperiodsynchronouswithVPA2
11:MeasurementperiodsynchronouswithVPA3
MTRPOLES? ‐ ‐ ‐
RespondswiththeNR3settingforthenumberofmotorpoles(setwiththe
MTRPOLEScommand)
MTRSLIP? ‐ ‐ ‐
RespondswiththeNR1selectioncontrollingthecalculationofmotorslip‐
0:nomotorslipcalculation
1:motorslipusesthefrequencyfromVPA1asthedrivefrequency
2:motorslipusesthefrequencyfromVPA2asthedrivefrequency
3:motorslipusesthefrequencyfromVPA3asthedrivefrequency
PERIOD? v VDEF ‐
RespondswiththeNR1measurementperiodsettingforVPAv–
0:VLF
1:LF
2:10Hz/0.3s
3:20Hz/0.1s
4:45Hz/20ms
5:150Hz/10ms
6:500Hz/2ms
7:FullsynchronizationwithVPA1
8:FullsynchronizationwithVPA2
RESPONSE? v VDEF ‐
RespondswiththeNR1measurementresponsesettingforVPAv–
0:Fastest
1:Medium
2:Slow
3:Slowest
SCOPEINRUSH? ‐ ‐ ‐
RespondswithaNR1–
0:BANDWIDTHandARANGEwillnotbeoverriddenduringascopedatacapture.
1:BANDWIDTHandARANGEwillbeoverriddenduringascopedatacapture.
