9 WIRINGTOCHANNELS
ThissectionshowstypicalwiringtoeachchannelineachVPAmatchingtheconfigurationWIRINGsettingforthatVPAintheXT2640
MEASCONFIGmenu.
9.1 1ØWIRINGUSINGINTERNALCURRENTMEASUREMENT

CAUTION:
 FORUSEWITHSH,SD,AH,AD,LH,LD,WHORWDCHANNELSONLY
 DONOTCONNECTWIRINGWHILEVOLTAGEPRESENT.
 ENSUREWIRINGISCORRECTBEFOREAPPLYINGVOLTAGE.
 DONOTPASSLOADCURRENT>2ArmsWITHTHEXT2640TURNEDOFF.
WIRING:
 Thickerconnectionsarecurrentcarrying.Ensurewireusedisratedforthemaximumvoltageandcurrenttobe
encountered.
 Thinnerconnectionsarenotcurrentcarrying.Ensurewireusedisratedforthemaximumvoltagetobeencountered.

Thewiringconnectionsshownaboveensurethebestoverallsystemaccuracyinmostcircumstances,measuringthe
voltageatthesourceandtheloadcurrent.Forapplicationsrequiringaccuratemeasurementsofthepowertotheload
whenusinglowvoltages(<50V)andhighcurrents(>1A)changetheREDV+terminalconnectiontothatoftheBLUEA‐
terminalinsteadoftheYELLOWA+terminalshownabove,thisensuresthatthevoltagedropacrosstheAterminaldoes
notaffecttheVmeasurement,attheexpenseofthecurrentandpowermeasurementsincludingthecurrentandpower
drawnbytheVinput(whichmaybeadjustedforbyusingtheADJUSTsettingintheMEASCONFIGscreen).
XT2640CONFIGURATION:
 IntheXT2640MEASCONFIGmenuyoushouldsetSCALEforthechanneltoOFF.
 ForeitherconnectionmethodyoumayusetheADJUSTsettingintheMEASCONFIGmenutosettheXT2640toadjustthe
signalsfortheconnectionmethodandwhethersourceorloadresultsarerequired.


A
V
L or
HI
N or
LO
L or
HI
N or
LO
From
SOURCE
To
LOAD

XT2640
CH
