XT2640OperatingManual 13July2016 Page158of187

Sub‐Field
Sub‐field
Format
Value Description
LOSS Realpowerloss(inW)
EFFICIENC
Y
or
EFF
Realpowerefficiency(in%)
VAR Imaginarypower(inW)
VA Apparentpower(inVA)
PF Powerfactor
SPEED Motorspeed(inrpm)
SLIP Motorslip(in%)
TORQUE Motortorque(inNm)
LOADZ Loadimpedance(inohms)
MeasurementSource KEYWORD
CH1,CH2,CH3or
CH4
CH1isDEFAULTifnootherMeasurementSourcesub‐fieldfound
Dataisfromtheselectedchannel
A1,A2,A3,VPA1,
VPA2orVPA3
DataisfromtheselectedVPA
MOTOR
Dataisamotormeasurementresult(onlytheDatafieldisusedwith
this,anyotherfieldsareignored)
IN DataisfromtheINefficiencygroup
MIDDLE DataisfromtheMIDDLEefficiencygroup
OUT DataisfromtheOUTefficiencygroup
IN‐MID DataisfromtheINefficiencygrouptotheMIDDLEefficiencygroup
IN‐OUT DataisfromtheINefficiencygrouptotheOUTefficiencygroup
MID‐OUT DataisfromtheMIDDLEefficiencygrouptotheOUTefficiencygroup
2
nd
MeasurementSource
(ignoredifMeasurement
SourceisnotaVPA)
KEYWORD
pA…D Dataisfromthe1
st
through4
th
(resp.)channeloftheselectedVPA
pAC
DataisthevoltagemeasuredbetweenphasesAandCoftheselected
VPA
pAB
DataisthevoltagemeasuredbetweenphasesAandBoftheselected
VPA
pBC
DataisthevoltagemeasuredbetweenphasesBandCoftheselected
VPA
pN DataistheneutralcurrentoftheselectedVPA
TOTALor
AVERAGE
DEFAULTifnoother2
nd
MeasurementSourcesub‐fieldfound
DataisthetotalfortheselectedVPA,exceptforVOLTSandAMPSdata
whichistheaverageofallchannels/phasesintheselectedVPA
MeasurementType KEYWORD
DC DataistheDCcomponent
AC DataistheACcomponent
ACDC orRMS DataistheACDCcomponent
COUPLED
DEFAULTifnootherMeasurementTypesub‐fieldfound
DataistheDC,ACorACDCcomponentasconfiguredfortheVPA
CF Dataisthecrestfactor(ACDC)
PK Dataispeak(ACDC)
VALLEY Dataisvalleypeak
PK‐VLY Dataisthedifferencebetweenpeakandvalleypeak
HIPK Dataisthehighestpeak(includingpolarity,ACDCcoupled)
LOPK Dataisthelowestpeak(includingpolarity,ACDCcoupled)
THDF DataisTHDrelativetofundamentalamplitude(in%)
THDSIG DataisTHDrelativetoACDC amplitude(in%)
H1orH2orH3
Dataisharmonicamplitudedata forthe1
st
,2
nd
or3
rd
harmonic
respectively
P1
Dataisharmonicphasedataforthefundamental(indegreeswith±180°
range)
HLIST
Dataisalistoftheharmonicamplitudesforeachharmonic.
ThismayonlybeusedwiththeLOGDATAcommand,andonlywitha
channelMeasurementSource,andonlywithvoltageorcurrent
MeasurementData.
EndingHarmonic(onlyusedif
MeasurementTypeisHLIST)
NR1 1to500
Thissub‐fieldisonlyusedwithaMeasurementTypeofHLIST;ifpresent
itisignoredforothermeasurementtypes.
Dataincludesharmonicsuptoandincludingthisnumber(ifthissub‐
fieldisnotspecifiedthenthedataincludesallallowableharmonics,i.e.
either100or500dependingonifH500isinstalled)

Alistofallowedcombinationsisprovidedbelow.Inthislistthefollowingcodesareusedtoreducethelengthofthelist–
CHn AnyofCH1,CH2,CH3orCH4
An AnyofA1,A2orA3
pX AnyofpA,pB,pCorpD
Hn AnyofH1…3
Notallcombinationsshownmaybeallowedinallcircumstances;channelsmightnotbeinstalledortheconfigurationmaynot
providevalidresultsforaspecificcombination.Notallvalidcombinationsmaybeshownbelowandwhereadefaultsub‐fieldvalue
maybeusedthecombinationisonlyshownwithoutdefiningthatspecificsub‐field.
FREQ:CHn
FREQ:An
VOLTS:CHn:DC
VOLTS:CHn:AC
VOLTS:CHn:ACDC
VOLTS:CHn
VOLTS:CHn:CF
VOLTS:CHn:PK
