FRONT BRAKE
4-16
Disassembling the front brake calipers
Order Job/Parts to remove Q’ty Remarks
1 Brake caliper piston 2
2 Brake caliper piston seal 2
3 Brake caliper dust seal 2
4 Bleed screw 1
For assembly, reverse the disassembly pro-
cedure.
1
3
2
4
New
New
T
R
.
.
6 Nm (0.6 m • kg, 4.3 ft • Ib)
BF
S
