Yamaha XT250X - Page 247

SIGNALING SYSTEM
7-22
The tail/brake light fails to come on.
The turn signal light, turn signal indicator light or both fail to blink.
1. Check the tail/brake light bulb and
socket.
Refer to
“CHECKING THE BULBS
AND BULB SOCKETS” on page 7-36.
NG→
Replace the tail/brake light bulb, socket or
both.
OK↓
2. Check the front brake light switch.
Refer to “CHECKING THE
SWITCHES” on page 7-33.
NG→ Replace the front brake light switch.
OK↓
3. Check the rear brake light switch.
Refer to
“CHECKING THE
SWITCHES” on page 7-33.
NG→ Replace the rear brake light switch.
OK↓
4. Check the entire signaling system’s
wiring.
Refer to
“CIRCUIT DIAGRAM” on page
7-19.
NG→
Properly connect or repair the signaling
system’s wiring.
OK↓
This circuit is OK.
1. Check the turn signal light bulb and
socket.
Refer to
“CHECKING THE BULBS
AND BULB SOCKETS” on page 7-36.
NG→
Replace the turn signal light bulb, socket or
both.
OK↓
2. Check the turn signal switch.
Refer to “CHECKING THE
SWITCHES” on page 7-33.
NG→
Poor conducting of turn signal switch.
Replace the left handlebar switch.
OK↓
3. Check the turn signal relay.
Refer to
“CHECKING THE RELAYS”
on page 7-40
.
NG→ Replace the turn signal relay.
OK↓
4. Check the entire signaling system’s
wiring.
Refer to
“CIRCUIT DIAGRAM” on page
7-19.
NG→
Properly connect or repair the signaling
system's wiring.
OK↓
Meter assembly
