B95W
Maintenance
134 / 306
6
06_Wartung und Pflege_en.fm - V1.0 - 1.8.17
20
Check engine oil level
Fig. 6-5 Check engine oil level
1 Filler cap
2 Oil dip stick
3 Engine oil filter
4 Oil drain plug
Check the oil level every day before starting, with the machine in a horizontal
position.
Clean the oil dipstick (2) and insert it as far as the stop.
J The notches on the oil dipstick (2) indicate the min. and max. oil levels.
Unscrew the sealing cover (1) and, if necessary, top up with engine oil from
a clean vessel.
Close the sealing cover.
After adding engine oil, wait at least 5 minutes before checking the engine oil
level again.
1
3
4
2
