B95W
Maintenance
170 / 306
6
06_Wartung und Pflege_en.fm - V1.0 - 1.8.17
20
Replace ventilation filter
Fig. 6-27 Replace ventilation filter
1 Ventilation filter
2 O-ring
Remove the ventilation filter (1) and dispose of it according to regulations.
Screw the new ventilation filter (1) with O-ring (2) and tighten by hand.
Notice
The ventilation filter must be replaced if it is soiled, e.g. by oil mist.
